3M 7100188265 Pleated Air Filter Merv 11 16x20x1 Inches

Product Description

The 3M 7100188265 is an electrostatic pleated air filter rated MERV 11 with 88% particle capture efficiency. It fits standard 16 x 20 x 1 inch filter slots and uses a polypropylene media to capture airborne particles including dust, pollen, mold spores, and pet dander. The integrated frame holds the media securely in place and maintains filter shape during service. At 0.47 pounds, it is lightweight and straightforward to handle during a filter changeout. This filter is appropriate for residential and light commercial forced-air systems where MERV 11 performance is specified or required by system design.

This filter is used in forced-air HVAC systems including gas furnaces, heat pumps, and air handlers equipped with standard 1-inch filter tracks. It is suited for residential applications where improved air quality is a priority without requiring the higher static pressure drop associated with MERV 13 or higher filters. HVAC technicians and property maintenance personnel typically install this filter during routine preventive maintenance visits. The 16 x 20 x 1 inch nominal size is one of the most common filter dimensions in residential construction.

Key Features

• MERV 11 rating with 88% particle capture efficiency for mid-range filtration performance
• Electrostatic polypropylene media enhances particle attraction and retention
• Nominal size 16 x 20 x 1 inches; actual dimensions 19.72 x 15.72 x 0.84 inches
• Integrated frame provides structural support and prevents bypass air leakage
• Lightweight at 0.47 pounds for easy single-technician handling
• Sold individually; minimum order quantity of 4 units

Compatibility

Designed as an OEM-style replacement for residential and light commercial forced-air HVAC systems requiring a nominal 16 x 20 x 1 inch MERV 11 pleated filter.

Installation Notes

Installation is performed by HVAC technicians or qualified maintenance personnel. Always set the system thermostat to the off position and confirm the air handler blower has stopped before opening the filter access panel. Insert the filter with the airflow direction arrow on the frame pointing toward the blower. Follow local codes and the equipment manufacturer's recommended filter change intervals, typically every 30 to 90 days depending on occupancy and air quality conditions.
