3M 7100166354 Adhesive Transfer Tape 1 in 540 Yd

Product Description

The 3M 7100166354 is an adhesive transfer tape designed for instant, aggressive bonding across a wide range of substrates including metals, glass, wood, paper, paint, and many plastics. Built around the 3M acrylic adhesive 400 system, the tape bonds on contact and maintains strong adhesion in temperatures up to 250 degrees F. The roll measures 1 inch wide and 540 yards long, making it well suited for high-volume production runs. A 60-weight unbleached densified kraft liner supports both manual and automated hand applications, and the liner releases cleanly for consistent tape lay-down.

This transfer tape is used in commercial print environments where reliable, high-speed splicing is required. It performs on high-speed flying splices and zero-speed splices across most grades of paper stock. Beyond print, it is applied in light manufacturing, signage, and general assembly wherever a thin, permanent adhesive layer must bond dissimilar materials without adding bulk. Installers and production technicians in print shops and light industrial settings are the primary users.

Key Features

• Acrylic adhesive 400 bonds on contact with aggressive, immediate tack
• Bonds metal, glass, wood, paper, paint, and many plastics
• Maintains strong bonds at temperatures up to 250 degrees F
• 60-weight unbleached densified kraft liner for manual and hand applications
• Clean liner release supports consistent, repeatable application
• Suited for high-speed flying splices and zero-speed splices on most paper grades

Compatibility

Designed for use on most grades of paper in commercial print applications, and compatible with a broad range of substrates including metals, glass, wood, painted surfaces, and many plastics.

Installation Notes

Application is typically performed by production technicians or assembly workers familiar with pressure-sensitive tape systems. Ensure the bonding surface is clean, dry, and free of oils or contaminants before application for best adhesion. Apply firm, even pressure across the tape after placement to activate full contact bond. No tools or heat are required for standard application.

Technical Specifications

• Width: 1 inch
• Length: 540 yards
• Maximum Service Temperature: 250 degrees F
• Liner Type: 60-weight unbleached densified kraft
• Adhesive Type: Acrylic 400
• Tape Color: Transparent
• Unit of Measure: Roll
• Package Weight: 4.44 pounds
• Package Dimensions: 8.3 x 8.3 x 10.6 inches
• UPC: 00021200564840

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100166354
