3M 7100122770 Aluminum Oxide Cloth Belt 80 Grit 48x6 in

Product Description

The 3M 7100122770 is an aluminum oxide cloth-backed abrasive belt designed for general-purpose metalworking and woodworking applications. Running on a polyester waterproof backing rated at XF weight, this belt handles both wet and dry service without delaminating under load. The resin bond resists high heat and pressure generated during aggressive stock removal. At 80 grit, the belt removes material efficiently while maintaining a consistent scratch pattern across the workpiece. It is sold individually and suited for production and maintenance environments where reliable, repeatable abrasive performance is required across a range of substrates.

This belt is optimized for use on mild steel and carbon steel, and performs well on softer metals including aluminum, bronze, and brass. It is also suitable for some woodworking operations. Compatible with backstand and benchtop belt sanders, and rated for stroke sanding, portable belt grinding, and wide belt grinding and finishing operations. The 48 inch length and 6 inch width fit commonly available industrial belt sanding machines used in metal fabrication shops, maintenance facilities, and woodworking operations.

Key Features

• Aluminum oxide abrasive mineral provides consistent, reliable cut on a wide range of substrates
• XF-weight polyester cloth backing withstands grinding pressure and heavy sanding loads
• Waterproof backing construction supports both wet and dry sanding or grinding applications
• Resin bond resists heat and pressure for extended belt life in production use
• 80 grit rating suited for metal deburring and general stock removal operations
• Compatible with backstand, benchtop, stroke, portable belt, and wide belt grinding equipment

Compatibility

Suitable for use on backstand and benchtop belt sanders, stroke sanders, portable belt grinders, and wide belt grinding and finishing machines accepting a 48 inch by 6 inch belt. Effective on mild steel, carbon steel, aluminum, bronze, and brass, as well as select woodworking applications.

Installation Notes

Install and tension the belt according to the machine manufacturer specifications before operation. Power down and lock out the sanding or grinding machine before changing belts. Inspect the belt for tears or edge damage before mounting, and confirm belt tracking is centered before resuming operation under load.

Technical Specifications

• Abrasive Mineral: Aluminum Oxide
• Grit: 80
• Belt Length: 48 inches
• Belt Width: 6 inches
• Backing Material: XF-Weight Polyester Cloth
• Bond Type: Resin
• Color: Maroon
• Application: Wet or Dry
• Weight: 9.64 pounds
• Unit of Measure: Each

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100122770
