3M 7100116999 Foil Tape White 4 Inch 45.72 Yd

Product Description

The 3M 7100116999 is the VentureClad 1577CW-WM insulation jacketing tape, a white aluminum multi-layered laminate foil tape engineered for all-weather jacketing applications on mechanical insulation systems. It delivers zero permeability, functioning as an absolute vapor barrier, and bonds securely in cold-weather conditions down to -10 degrees F. The cold-weather acrylic adhesive makes field application straightforward without specialized tools. HVAC and mechanical insulation contractors rely on this tape for above-ground and outdoor pipe and duct insulation finishes where moisture infiltration and UV degradation are primary concerns.

This tape is suited for residential and commercial mechanical insulation jacketing, including pipe insulation, duct wrap, and equipment insulation finishing. Its flexible backing conforms to irregular, curved, and contoured surfaces, making it practical on fittings, elbows, and transitions. The product meets FDA compositional requirements for indirect food contact, making it appropriate for food-processing and cold-storage facility applications where incidental contact compliance is required. It also qualifies for LEED compliance credit consideration when applicable.

Key Features

• Zero permeability acts as an absolute vapor barrier for sealing and jacketing applications
• Cold-weather acrylic adhesive applies at temperatures as low as -10 degrees F (-23 degrees C)
• High puncture and tear resistance for durability across extreme environmental conditions
• Superior resistance to weathering, mold, and UV exposure
• Flexible backing conforms to curved and irregular surfaces without special tools
• Meets FDA compositional requirements for indirect food contact
• Qualifies for LEED compliance credit when applicable

Compatibility

Designed for use as an insulation jacketing tape on mechanical pipe insulation, duct wrap, and equipment insulation finishes in commercial and industrial HVAC and plumbing applications.

Installation Notes

Installation is typically performed by licensed HVAC or mechanical insulation contractors. Surfaces must be clean, dry, and free of oils or loose material before tape application. No special tools are required for cutting or applying on-site. Follow 3M installation guidelines to qualify for the stated 10-year warranty coverage.

Technical Specifications

• Tape Width: 4 inches
• Tape Length: 45.72 yards per roll
• Color: White
• Backing Material: Aluminum multi-layered laminate
• Adhesive Type: Cold-weather acrylic
• Minimum Application Temperature: -10 degrees F (-23 degrees C)
• Vapor Permeability: Zero
• Unit of Measure: Roll
• Package Weight: 17.713 pounds
• Package Length: 13.88 inches
• Package Width: 13.88 inches
• Package Height: 4.75 inches
• Warranty: 10 years (when applied per 3M installation guidelines)
• UPC: 076308982817

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100116999
