3M 7100095214 Abrasive Belt 361F P220 Grit 75x37 Inch

Product Description

The 3M 7100095214 is a coated abrasive cloth belt in the 361F series, designed for grinding, blending, deburring, and finishing operations on metal surfaces. Running on a polyester backing with aluminum oxide abrasive grains bonded by a heat-resistant resin system, this belt delivers consistent cut rates and controlled surface finish across medium-pressure applications. At 75 inches long and 37 inches wide, it suits wide-belt equipment used in sheet and coil processing. The P220 grit rating targets fine finishing and light deburring passes where surface quality is the priority.

This belt is suited for stainless steel coil finishing lines, backstand grinders, and centerless belt machines in both fabrication shops and production grinding environments. The flexible polyester backing conforms to workpiece contours without breaking down prematurely. Wet and dry operation is supported, making it compatible with coolant-assisted grinding setups as well as dry finishing stations. Typical users include metalworking fabricators, weld finishing technicians, and industrial maintenance machinists working on ferrous and non-ferrous stock.

Key Features

• Aluminum oxide abrasive grains deliver fast cut and broad surface compatibility on metals including stainless steel
• Tough polyester backing maintains dimensional stability under medium-pressure grinding conditions
• Heat-resistant resin bond resists breakdown under elevated temperatures, pressure, and wet coolant exposure
• Suitable for both wet and dry grinding and finishing applications
• Designed for centerless, backstand, and wide-belt coil and sheet grinding setups

Compatibility

Designed as an OEM-style replacement abrasive belt for wide-belt, backstand, and centerless grinding machines accepting a 75-inch by 37-inch belt format.

Installation Notes

Belt installation and replacement should be performed by a qualified machinist or maintenance technician with the grinding machine fully de-energized and locked out per OSHA lockout/tagout procedures. Verify belt tracking alignment and tension settings against the machine manufacturer specifications before resuming operation. Inspect the belt splice and backing for damage before each use and do not exceed the equipment speed rating marked on the machine.

Technical Specifications

• Belt Length: 75 inches
• Belt Width: 37 inches
• Grit: P220
• Abrasive Material: Aluminum Oxide
• Backing Material: Polyester Cloth
• Bond Type: Heat-Resistant Resin
• Application Type: Wet and Dry
• Weight: 4.1 pounds
• UOM: Each
• Minimum Order Quantity: 5
• UPC: 00051111512166

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100095214
