3M 7100067208 Cubitron Ii 775L 5 Inch 180 Grit Abrasive Disc

Product Description

The 3M 7100067208 is a coated abrasive film disc roll in the Cubitron II 775L series, engineered for high-speed stock removal on metal, composites, and other industrial substrates. At the core of its performance is 3M Precision Shaped Grain technology, which uses triangular ceramic mineral structures to slice through material rather than plowing or gouging like conventional abrasives. This geometry produces a disc that cuts up to 2 times faster and lasts up to 6 times longer than standard abrasive discs. At 5 inches in diameter and 180 grit, this disc is suited for finishing and blending passes where controlled material removal matters. It ships in roll format with a Stikita pressure-sensitive adhesive backing for fast disc changes.

The 775L disc roll is intended for use in production and maintenance environments where consistent stock removal and surface prep are required. The film backing resists tearing and maintains edge integrity through extended use, making it appropriate for both flat and contoured surfaces. Typical applications include weld blending, surface preparation, and light deburring on metal fabrication work. The roll format supports high-volume operations where downtime from disc changes adds up. Installation-level trades and fabrication shops working with random orbital or disc sanders in the 5-inch platform will find this disc compatible with their existing tooling when paired with an appropriate Stikita backup pad.

Key Features

• 3M Precision Shaped Grain ceramic mineral slices rather than plows, reducing heat and loading
• Cuts up to 2 times faster than conventional abrasive discs
• Service life up to 6 times longer than conventional abrasives
• Film backing provides greater tear resistance and edge retention versus paper-backed alternatives
• Stikita pressure-sensitive adhesive attachment system enables rapid disc changes without tools
• Suited for a wide range of substrates with primary focus on stock removal applications

Compatibility

Designed for use with 5-inch random orbital sanders and disc grinders equipped with a Stikita-compatible backup pad. No specific model compatibility data was provided in the product input.

Installation Notes

Disc installation requires a clean, dry Stikita backup pad surface for proper adhesion. Ensure the tool is powered off and disconnected before mounting or removing discs. Inspect the disc for tears or edge damage before each use, and do not operate beyond the disc speed rating marked on the roll packaging. Worn or damaged discs should be removed from service immediately.

Technical Specifications

• Series: Cubitron II 775L
• Disc Diameter: 5 inches
• Grit: 180
• Abrasive Type: Precision Shaped Ceramic Grain
• Backing: Film
• Attachment: Stikita (Pressure-Sensitive Adhesive)
• Coating Type: Coated
• Unit of Measure: Roll
• Package Weight: 4.4 pounds
• Package Length: 13 inches
• Package Width: 7.75 inches
• Package Height: 4.38 inches
• Minimum Order Quantity: 4
• UPC: 076308642803

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100067208
