3M 7100007190 Diamond Grade Conspicuity Marking Roll Red

Product Description

The 3M 7100007190 is a Diamond Grade conspicuity marking roll (series 983-72 ES) in red, designed for high-visibility retroreflective marking on commercial trucks, trailers, and large vehicles. The roll measures 4 inches wide by 150 feet long and features microprismatic sheeting technology that delivers superior retroreflectivity compared to standard reflective tape. A pressure-sensitive adhesive with a protective liner and premask backing allows for clean, consistent application without additional adhesives or specialized equipment. Fleet operators, body shops, and DOT compliance technicians use this tape to meet federal reflective marking requirements on heavy vehicles.

This conspicuity tape is suited for exterior marking on Class 7 and Class 8 trucks, semi-trailers, flatbeds, and other large commercial vehicles where retroreflective identification is required by federal or state regulation. The premask and pre-cut strip format makes field application practical for service shops performing DOT compliance work or new vehicle outfitting. The red color is used in combination with white tape to form the alternating pattern required under FMCSA conspicuity standards.

Key Features

• Microprismatic sheeting construction for high retroreflectivity
• Pressure-sensitive adhesive with liner and premask for controlled application
• 4-inch width x 150-foot roll length for extended coverage per roll
• Red color for use in alternating DOT conspicuity marking patterns
• Pre-cut strip format simplifies alignment and reduces waste during installation

Compatibility

Designed for exterior retroreflective marking applications on commercial trucks, trailers, and large vehicles requiring DOT-compliant conspicuity tape.

Installation Notes

Installation is typically performed by fleet maintenance technicians or body shop professionals familiar with FMCSA and DOT conspicuity marking requirements. Surfaces should be clean, dry, and free of oil, wax, or loose coatings before tape application to ensure proper adhesion. Apply firm pressure along the full length of the tape to seat the adhesive, and allow adequate dwell time before vehicle re-entry into service. Consult applicable federal and state regulations to confirm placement patterns, coverage areas, and color sequencing requirements.

Technical Specifications

• Width: 4 inches
• Length: 150 feet
• Color: Red
• Series: 983-72 ES
• Unit of Measure: Roll
• Weight: 6.46 pounds
• UPC: 00051138678241

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100007190
