3M 7100001967 Conductive Cushioning Gasket ECG-7073H

Product Description

The 3M 7100001967 is an electrically conductive cushioning gasket tape, sold under the ECG-7073H product line, designed for shielding and grounding applications in electronic assemblies and enclosures. This single-coated tape format delivers measurable electrical conductivity along with strong cushion and recovery performance, making it suitable for EMI/RFI sealing applications where both mechanical compliance and electrical continuity are required. The roll format measures 500 millimeters wide by 50 meters long with a 0.73 millimeter thickness, offering substantial coverage for production-scale or large-format gasketing work. Electronics assembly technicians and enclosure fabricators typically specify this product.

ECG-7073H is applied in applications requiring a compressible interface between mating conductive surfaces, such as cabinet panels, chassis seams, and electronics enclosures. It is suited for both original equipment manufacturing and field service environments where EMI shielding continuity must be maintained across a gasketed joint. The roll format supports die-cutting or hand-cutting to custom gasket profiles. Both commercial electronics and industrial control enclosures represent typical use cases.

Key Features

• Single-coated tape format provides one adhesive face for secure mounting to a mating surface
• Electrically conductive construction maintains ground continuity and supports EMI/RFI shielding across joints
• Cushion and recovery properties allow the gasket to conform to surface irregularities and maintain contact under compression
• 500 millimeter width supports wide panel gasketing or efficient die-cut yield for smaller profiles
• 0.73 millimeter thickness provides a defined interface gap fill for controlled compression applications
• Roll format with 50 meter length is suitable for production-volume use

Compatibility

Designed as an OEM-style gasketing solution for electrically conductive sealing applications in electronics enclosures, EMI shielding assemblies, and similar environments requiring both mechanical cushioning and electrical continuity at a mated interface.

Installation Notes

Installation is typically performed by electronics assembly technicians or enclosure fabricators. Clean mating surfaces thoroughly before application to ensure full adhesive contact and consistent electrical conductivity across the gasket. Avoid stretching the tape during application, as dimensional changes may affect the compression set and electrical performance of the finished gasket. Follow applicable IPC or enclosure manufacturer guidelines for compression force and surface preparation.

Technical Specifications

• Width: 500 millimeters
• Length: 50 meters
• Thickness: 0.73 millimeters
• Weight: 35 pounds
• Unit of Measure: Roll
• Minimum Order Quantity: 1
• UPC: 00051115528842

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7100001967
