3M 7012819713 Lad-safa Cable Guide Vertical Safety

Product Description

The 3M 7012819713 is a bypassable intermediate cable guide for use with the Lad-Safa vertical cable safety system. It is designed to support and direct a steel safety cable that runs the full length of a fixed climbing area, such as a ladder or telecommunication tower. The guide features a non-metallic insert that prevents metal-to-metal contact with the cable, extending system life and reducing wear. Galvanized mounting hardware provides corrosion resistance for outdoor and industrial environments. This component is sold individually and is ordered alongside top and bottom brackets, stand-offs, guide supports, cable, and sleeve as part of a complete Lad-Safa system assembly.

This cable guide is suited for vertical fall protection installations on fixed ladders and telecommunication towers in both commercial and industrial settings. The Lad-Safa system supports straight and curved ladder configurations and can be mounted to wood, concrete, or steel structures. The system is designed to accommodate up to four workers simultaneously, making it applicable to high-traffic climb points on job sites. Licensed safety or rigging professionals typically perform the installation as part of a full vertical lifeline system build-out.

Key Features

• Bypassable intermediate cable guide compatible with the Lad-Safa vertical cable system
• Non-metallic guide insert prevents metal-to-metal contact with the safety cable
• Galvanized mounting hardware for corrosion resistance in outdoor and industrial use
• Designed for fast and simplified installation with fewer loose components than previous generations
• Compatible with systems serving up to four simultaneous climbers
• Sold as an individual component — order brackets, stand-offs, cable, and sleeve separately

Compatibility

Designed for use with the 3M DBI-SALA Lad-Safa vertical cable safety system. Intended for use with the Lad-Safa X2 or X3 Sleeve to meet ANSI Z359.16 requirements. Compatible with installations on fixed ladders and telecommunication towers mounted to wood, concrete, or steel structures.

Installation Notes

Installation should be performed by a qualified fall protection or rigging professional in accordance with applicable ANSI Z359 standards and any governing local regulations. Before beginning work, de-energize or isolate any hazards in the climbing zone and follow the full Lad-Safa system installation instructions, ordering all required components — top bracket, bottom bracket, stand-offs, cable, and sleeve — as separate line items. Do not substitute non-system hardware or omit intermediate cable guides, as proper cable guidance is critical to system performance during a fall event.

Technical Specifications

• Weight: 1.21 pounds
• Length: 5 inches
• Width: 7 inches
• Height: 1 inch

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7012819713
