3M 7010397928 Scotch Super 33+ Vinyl Electrical Tape 600 V (0.75 in x 52 ft) 3MT054007-06133

Product Description

3M 7010397928 Scotch Super 33+ Vinyl Electrical Tape is a 7 mil PVC electrical tape that provides electrical insulation for wires and cables rated up to 600 V. It uses a rubber-based pressure-sensitive adhesive and elastic PVC backing to provide moisture-tight electrical and mechanical protection. The flame-retardant tape withstands temperatures from 0 to 221 °F (18 to 105 °C) and is compatible with solid dielectric and synthetic cable insulations and splicing compounds.

• 7 mil thickness with high conformability for insulation, splicing and overwrap applications
• Rubber-based pressure-sensitive adhesive on elastic PVC backing provides moisture-tight electrical and mechanical protection
• Flame-retardant; temperature range 0 to 221 °F (18 to 105 °C); resists oil, water, abrasion, chemicals and solvents; meets CSA, IEC 60454-3-1-7/F-PVC P/90, UL and VDE

Product Highlights

7 mil vinyl electrical tape, 0.75 in x 52 ft, rated to 600 V, rubber adhesive, elastic PVC backing, industry certifications

Product Information

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010397928
• Country of Origin: United States

Technical Specifications

• Brand: 3M
• MPN: 7010397928
• Replacement MPN: 3MT054007-06133
• Product Name: Scotch Super 33+ Vinyl Electrical Tape
• Series: Super 33+
• Type: Vinyl electrical tape
• Width: 0.75 in
• Length: 52 ft
• Size: 0.75 in x 52 ft (19 mm x 15.6 m)
• Thickness: 7 mil (0.007 in)
• Voltage Rating: Up to 600 V
• Dielectric Strength: 1150 V
• Temperature Range: 0 to 221 °F (18 to 105 °C)
• Material: Polyvinyl chloride (PVC)
• Backing Material: Elastic PVC backing
• Adhesive Type: Rubber-based pressure-sensitive adhesive
• Tensile Strength: 17 lb/in
• Adhesion Strength: 24 oz/in
• Elongation at Break: 200%
• Resistance Properties: Resists UV, abrasion, moisture, oil, chemicals, solvents, alkalis and acids; inhibits copper corrosion; weather resistant
• Certifications: CSA; IEC 60454-3-1-7/F-PVC P/90; UL Listed; VDE Marks License; RoHS compliant
• Unit of Measure: Roll
• Package Quantity (Roll): 1
• Package Quantity (Case): 100
• Country of Origin: United States
• Weight: 0.207 lb
