3M 7010373828 Adhesive Transfer Tape 3 Inch 60 Yd

Product Description

The 3M 7010373828 is an adhesive transfer tape built on 3M High Performance Acrylic Adhesive 350, delivering a reliable, high-strength bond across a wide range of surface energy materials. At 5.0 mils thick, the acrylic adhesive film bonds effectively to both high and low surface energy substrates, including powder coated paints and rougher surfaces. The adhesive is fiber reinforced for roll stability in narrow widths and to resist oozing during application. A tan 58 lb. polycoated kraft (PCK) paper liner provides moisture resistance and minimizes liner wrinkles during handling and dispensing. This tape is rated for short-term temperature exposure up to 450 degrees F and long-term service up to 300 degrees F.

This transfer tape is suited for industrial assembly, fabrication, and manufacturing applications where a clean, carrier-free adhesive bond is required. It performs well when joining dissimilar materials, bonding components with low surface energy plastics, or attaching parts with moderately rough surfaces. The low-odor formulation makes it appropriate for use in enclosed or semi-enclosed work environments. Each roll measures 3 inches wide and 60 yards long, packaged in a convenient roll format for hand or machine application.

Key Features

• 5.0 mil thick acrylic adhesive bonds high and low surface energy substrates and powder coated paints
• Fiber-reinforced adhesive resists oozing and maintains roll stability in narrow widths
• PCK paper liner provides moisture resistance and reduces liner wrinkling
• Short-term temperature resistance up to 450 degrees F and long-term up to 300 degrees F
• Excellent chemical resistance with strong shear and peel strength at elevated temperatures
• Low odor formulation suitable for enclosed work environments

Compatibility

Designed for bonding high and low surface energy materials, including powder coated paints and rougher substrates, in industrial assembly and fabrication applications.

Installation Notes

Surface preparation is critical before application — clean bonding surfaces thoroughly to remove oils, dust, and contaminants for maximum adhesion. Apply firm, even pressure across the tape after positioning to ensure full contact with the substrate. When working with the transfer tape, remove the PCK liner carefully to avoid stretching or distorting the adhesive film. Follow all applicable workplace safety guidelines when working with adhesive tapes in high-temperature environments.

Technical Specifications

• Adhesive Type: High Performance Acrylic Adhesive 350
• Tape Thickness: 5.0 mils
• Width: 3 inches
• Length: 60 yards
• Liner: Tan 58 lb. polycoated kraft (PCK) paper
• Short-Term Temperature Rating: 450 degrees F
• Long-Term Temperature Rating: 300 degrees F
• Color: Transparent
• Unit of Measure: Roll
• Weight: 1.17 pounds
• UPC: 00021200396090

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010373828
