3M 7010373205 Vinyl Foam Tape 4516 Black 5/8in X 36yd

Product Description

The 3M 7010373205 is a black vinyl foam tape sold as Tape 4516, a single-coated, closed-cell foam tape designed for bonding and sealing applications across a wide range of surfaces. The tape is conformable, allowing it to follow irregular contours and gaps without lifting. At 1/16 inch thick, it provides a low-profile seal that compresses reliably under light clamping or fastening pressure. Each roll measures 5/8 inches wide by 36 yards long. HVAC technicians, insulation installers, and general contractors commonly install this tape where a flexible, compressible seal is required between dissimilar materials or along panel edges.

Tape 4516 is suited for both residential and light commercial applications. Typical use cases include sealing ductwork joints, securing foam insulation seams, weather-sealing cabinet edges, vibration dampening between metal panels, and general gap-filling where a conformable foam layer is needed. The closed-cell foam construction resists moisture absorption, making it appropriate for installations in humid or outdoor-exposed environments. The single-coated adhesive bonds to metal, plastic, rubber, and painted surfaces commonly found in HVAC, plumbing, and electrical enclosure work.

Key Features

• Closed-cell vinyl foam construction resists moisture absorption
• Conformable body follows irregular surfaces and contours without lifting
• 1/16 inch thickness provides low-profile compression sealing
• 5/8 inch width suits narrow seam and edge-sealing applications
• 36-yard roll length reduces mid-job splicing on longer runs
• Single-coated adhesive bonds to metal, plastic, rubber, and painted surfaces

Compatibility

Designed as a general-purpose single-coated vinyl foam tape suitable for bonding and sealing on a variety of smooth and semi-smooth surfaces in HVAC, insulation, and light construction applications.

Installation Notes

Surface preparation is critical before application — clean and dry the substrate to remove oils, dust, and loose material for maximum adhesion. Apply firm hand pressure along the full length of the tape immediately after placement to activate the adhesive bond. In HVAC or duct applications, follow applicable mechanical codes and manufacturer duct-sealing guidelines. Remove the tape from the roll at room temperature when possible, as cold conditions can reduce initial tack.

Technical Specifications

• Tape Series: 4516
• Color: Black
• Material: Vinyl closed-cell foam
• Coating: Single-coated
• Thickness: 1/16 inch
• Width: 5/8 inches
• Length: 36 yards
• Unit of Measure: Roll
• Weight: 1.08 pounds
• UPC: 00021200037610

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010373205
