3M 7010369152 Aluminum Oxide Flap Wheel 8 Inch 180 Grit

Product Description

The 3M 7010369152 is an aluminum oxide flap wheel designed for aggressive stock removal, blending, finishing, and cleaning on metal workpieces. The coated abrasive flaps conform to contoured and radiused surfaces, making this wheel effective on both inside and outside diameters. A steel mandrel reduces chatter and operator fatigue during extended use. At 8 inches in diameter and 180 grit, this wheel delivers a consistent straight-line finish suited to a wide range of metalworking applications in fabrication, maintenance, and repair environments.

This flap wheel is used in metal fabrication shops, maintenance facilities, and industrial repair operations. It performs on ferrous and non-ferrous materials, including steel, aluminum, and other common metals. The wheel suits applications where consistent surface finish is required on curved or contoured parts such as pipes, tubes, and cylindrical workpieces. It is typically operated with a bench grinder, lathe, or drill press by machinists, fabricators, and maintenance technicians.

Key Features

• Aluminum oxide abrasive cuts quickly on ferrous and non-ferrous metals
• Coated flaps conform to contoured and radiused surfaces for consistent coverage
• Produces a straight-line finish on inside and outside diameters
• Steel mandrel minimizes chatter and reduces operator fatigue
• 180 grit suited for fine blending, finishing, and cleaning operations
• 8-inch diameter provides broad surface coverage per pass

Compatibility

Designed as an OEM-style replacement flap wheel for use with bench grinders, lathes, and drill press setups accepting an 8-inch diameter wheel with a standard mandrel attachment.

Installation Notes

Installation and mounting should be performed by a qualified machinist or fabricator familiar with abrasive wheel safety. Always power down and isolate the machine before mounting or removing the wheel. Verify that the equipment spindle speed does not exceed the maximum rated RPM marked on the wheel. Follow ANSI B7.1 and applicable shop safety standards when mounting and operating abrasive wheels.

Technical Specifications

• Diameter: 8 inches
• Grit: 180
• Abrasive Material: Aluminum Oxide
• Mandrel Material: Steel
• Package Dimensions: 8.63 inches x 8.63 inches x 7.25 inches
• Weight: 4.382 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 5
• UPC: 051115427522

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010369152
