3M 7010368579 Convolute Deburring Wheel 6 Inch

Product Description

The 3M 7010368579 is a convolute deburring wheel designed for medium to heavy precision deburring, blending, and polishing of machined and fabricated parts. The wheel bonds an open web of abrasive grain and resin to a rigid fiberglass core, producing a strong, dense structure that maintains its form under sustained contact with workpiece edges. Fine-grade silicon carbide mineral delivers sharp cutting action while leaving smooth surface finishes. At 6.63 inches in diameter and 4 pounds, this wheel is suited for bench grinder and pedestal grinder applications in machine shops, fabrication facilities, and production environments.

This deburring wheel is well suited to medium and heavy burr removal on parts with close tolerances. A common application is aluminum die cast flashing removal, where the conformable open-web structure follows part geometry without gouging. The wheel also performs on steel, stainless, and other ferrous and non-ferrous metals in industrial deburring operations. It is typically used by machinists, tool-and-die technicians, and fabrication personnel working in production or job-shop settings.

Key Features

• Fine-grade silicon carbide abrasive mineral for sharp cutting and smooth finishes
• Open web construction is load resistant, extending abrasive service life
• Conformable wheel geometry follows part contours and reduces gouging risk
• Medium to hard density stands up to edges and close-tolerance deburring
• Fiberglass core provides structural rigidity under continuous use
• Effective on aluminum die cast flashing and other precision-tolerance parts

Compatibility

Designed for use as a convolute deburring wheel on standard bench grinders and pedestal grinders accepting a 6-inch diameter wheel form.

Installation Notes

Installation and mounting should be performed by qualified personnel following the grinder manufacturer's instructions and applicable ANSI B11 safety standards for abrasive wheel machinery. Always power down and lockout the grinder before mounting or removing the wheel. Inspect the wheel for cracks or damage before each use and never exceed the maximum RPM rating marked on the wheel or its packaging. Eye protection and appropriate PPE are required during operation.

Technical Specifications

• Wheel Diameter: 6.63 inches
• Wheel Type: Convolute
• Abrasive Mineral: Silicon Carbide
• Grade: Fine
• Density: Medium to Hard
• Core Material: Fiberglass
• Weight: 4 pounds
• Package Width: 6.63 inches
• Package Height: 4.5 inches
• Unit of Measure: Each
• UPC: 051115370927

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010368579
