3M 7010365830 Surface Conditioning Belt 90x4 Inch Non-woven

Product Description

The 3M 7010365830 is a non-woven surface conditioning belt designed for metalworking and finishing applications. Built on a durable cloth and polyester scrim backing, this belt delivers moderate stretch resistance suited to consistent, controlled surface work. The open non-woven nylon web resists loading, extending abrasive service life across extended runs. At 90 inches long and 4 inches wide, it fits wide-belt and stroke-sander configurations common in metal fabrication shops. The aluminum oxide mineral with resin bond provides reliable, repeatable cutting action without aggressively marring the substrate surface.

This belt is used in metal finishing sequences where surface conditioning is required without altering the geometry of the workpiece. It performs on a range of substrates including stainless steel, carbon steel, and brass. Typical applications include blending weld seams, removing light scale, and preparing surfaces before coating or polishing. It is commonly specified by fabricators, maintenance machinists, and industrial finishing technicians working on flat and contoured metal parts.

Key Features

• Cloth and polyester scrim backing provides low-stretch stability during operation
• Springy non-woven nylon fibers condition surfaces while preserving workpiece geometry
• Open web construction resists loading and extends abrasive service life
• Aluminum oxide mineral with resin bond suits a wide range of metal substrates
• Versatile across multiple finishing sequences from blending to pre-coat prep

Compatibility

Designed as a replacement or production-run belt for wide-belt sanders and stroke sanders accepting a 90 inch by 4 inch non-woven abrasive belt.

Installation Notes

Belt installation should be performed by qualified machine operators following the sander manufacturer's tracking and tensioning procedures. Confirm the machine is fully de-energized and lockout/tagout procedures are in place before changing belts. Inspect the contact drum and platen for wear before mounting a new belt. Do not exceed the machine's rated belt speed for non-woven abrasive products.

Technical Specifications

• Belt Length: 90 inches
• Belt Width: 4 inches
• Backing Type: Non-woven cloth and polyester scrim
• Mineral Type: Aluminum Oxide (AO)
• Bond Type: Resin
• Weight: 1.37 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 10
• UPC: 00048011145334

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010365830
