3M 7010365525 Unitized Mounted Point B52 Surface Conditioning

Product Description

The 3M 7010365525 is a Scotch-Brite EXL unitized mounted point designed for delicate deburring and surface finishing on metal and plastic parts. Built in the B52 shape with a 1/8 inch shank, this mounted point uses EXL unitized surface conditioning technology that combines abrasive and fiber into a single, consistent structure. The result is uniform cut and finish throughout the life of the point, without the glazing or loading common in bonded abrasives. It carries a coarse (CRS) grade, making it well suited for initial deburring passes where controlled material removal is needed without aggressive surface damage.

This mounted point is used in precision deburring, edge blending, and light surface finishing of machined metal components and plastic parts. It fits standard die grinders and rotary tools with a 1/8 inch collet. The B52 ANSI shape makes it practical for reaching into recessed areas, slots, and contoured surfaces that flat or larger abrasive media cannot access. It is commonly found in fabrication shops, machine shops, and production environments where consistent finish quality across high part volumes is required.

Key Features

• EXL unitized construction delivers consistent cut and finish from first use to last
• B52 ANSI shape allows access to recessed features, slots, and contoured surfaces
• 1/8 inch shank fits standard die grinder and rotary tool collets
• Coarse (CRS) grade suited for initial deburring and controlled material removal
• Compatible with both metal and plastic workpieces without aggressive surface damage
• Unitized abrasive structure resists glazing and loading during use

Compatibility

Designed for use with standard die grinders and rotary tools accepting a 1/8 inch shank. Suitable for deburring and finishing applications on metal and plastic parts in production and fabrication settings.

Installation Notes

Install the mounted point into a die grinder or rotary tool with a compatible 1/8 inch collet and tighten securely before operation. Ensure the tool is powered off and unplugged before changing mounted points. Inspect the point for damage before each use and do not exceed the maximum RPM rating of the tool or abrasive. Wear appropriate personal protective equipment including eye protection when operating rotary abrasive tools.

Technical Specifications

• Shape: B52
• Shank Diameter: 1/8 inch
• Grade: Coarse (CRS)
• Technology: EXL Unitized Surface Conditioning
• Weight: 0.01 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 50
• UPC: 00048011648002

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010365525
