3M 7010365134 Scotch-brite Exl Unitized Wheel 12 in Ao

Product Description

The 3M 7010365134 is a Scotch-Brite EXL Unitized Abrasive Wheel designed for smoothing, deburring, and surface finishing on metal alloys, plastics, and composites. The wheel measures 12 inches in diameter with a 1.25-inch arbor bore and ships at 2 pounds. Its layered, unitized construction uses aluminum oxide (AO) abrasive bonded throughout the wheel body, delivering consistent cut and finish performance from edge to core. Machinists, fabricators, and finishing technicians use this wheel on bench grinders and automated robotic finishing cells where conformable abrasive contact is required across contoured or complex-shaped workpieces.

This unitized wheel is suited for both manual and robotic finishing applications across light manufacturing, metal fabrication, and composites work. It is appropriate for use on ferrous and non-ferrous metal alloys, as well as many plastics and composites. The wheel can be dressed at the edge to optimize contact geometry for deburring, polishing, or blending operations. It is sold individually and operates in either clockwise or counterclockwise rotation, making it compatible with standard bench and pedestal grinder setups.

Key Features

• Soft, conformable construction keeps abrasive in contact with complex and irregular part geometries
• Layered unitized build supports operation in both clockwise and counterclockwise directions
• Wheel edge can be dressed for targeted deburring, finishing, or polishing profiles
• Minimizes heat buildup, reducing risk of thermal damage on heat-sensitive materials
• Resists smearing for cleaner cut surfaces and reduced prep between passes
• Available in a range of densities from soft and conformable to hard and aggressive for varied application requirements

Compatibility

Designed for use on bench grinders, pedestal grinders, and robotic finishing systems equipped with a 1.25-inch arbor. Suitable for finishing, deburring, and polishing operations on metal alloys, plastics, and composites.

Installation Notes

Installation and wheel mounting should be performed by a qualified machinist or maintenance technician following the grinder manufacturer's arbor and flange specifications. Power down and lock out the grinder before mounting or removing the wheel. Verify that the machine's rated RPM does not exceed the wheel's maximum operating speed before running. Inspect the wheel for damage before each use and do not operate a cracked or delaminated wheel.

Technical Specifications

• Diameter: 12 inches
• Arbor Size: 1.25 inches
• Abrasive Type: Aluminum Oxide (AO)
• Construction: Unitized
• Package Weight: 2 pounds
• Overall Dimensions: 12.5 x 12.5 x 1.69 inches
• Unit of Measure: Each
• UPC: 00048011279886

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010365134
