3M 7010361583 Abrasive Belt 70x1-1/4 Inch 24 Grit

Product Description

The 3M 7010361583 is a coated abrasive belt designed for high-pressure grinding and edge work on metal substrates. It uses alumina zirconia abrasive grain with a grinding aid, which delivers greater cutting efficiency than standard aluminum oxide belts. The belt features a heavy polyester cloth backing that is water-resistant and built to handle demanding production environments. At 70 inches long and 1-1/4 inches wide with a 24 grit designation, it is sized for stationary and portable belt grinding applications. Licensed trades and metalworking shops use this belt where consistent cut rate and durability under load are required.

This belt is suited for industrial and production grinding on ferrous and non-ferrous metals, including aluminum and stainless steel. The alumina zirconia mineral runs cooler than aluminum oxide, reducing heat buildup on heat-sensitive materials. It performs well on weld blending, deburring, and surface conditioning tasks. The 24 grit rating makes it appropriate for aggressive stock removal rather than finishing passes. It is sold individually and is typically used in high-cycle production settings where belt life and cut rate directly affect throughput.

Key Features

• Alumina zirconia grain with grinding aid for higher cutting power than aluminum oxide
• Heavy water-resistant polyester cloth backing handles high-pressure and edge work
• Runs cool — suitable for heat-sensitive metals including aluminum and stainless steel
• 24 grit for aggressive stock removal and fast material takedown
• 70 inch length and 1-1/4 inch width for stationary belt grinder fitment

Compatibility

Designed for use on belt grinders and sanders accepting a 70 inch by 1-1/4 inch abrasive belt. Suitable for grinding and finishing applications on metal, including stainless steel and aluminum.

Installation Notes

Belt installation should be performed by a qualified operator following the machine manufacturer's guidelines for tracking and tensioning. Power down and lock out the grinder before mounting or removing the belt. Inspect the belt for tears or edge damage before each use and do not exceed the machine's rated operating speed. Ensure the belt arrow or run direction marking, if present, is oriented correctly before startup.

Technical Specifications

• Abrasive Grain: Alumina Zirconia
• Grit: 24
• Belt Length: 70 inches
• Belt Width: 1-1/4 inches
• Backing Material: Heavy polyester cloth, water-resistant
• Weight: 0.46 pounds
• UOM: Each
• UPC: 00051115271298

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010361583
