3M 7010360488 Abrasive Belt 20.5x0.75 Inch Ao Cloth

Product Description

The 3M 7010360488 is a Trizact 237AA abrasive belt designed for intermediate finishing and fine polishing applications. It uses 3M microreplication technology in which micron-graded aluminum oxide particles are formed into three-dimensional pyramids and bonded to an X-weight cloth backing. As the pyramids wear, fresh sharp mineral is continuously exposed, producing a consistent cut rate and a predictable fine finish throughout the life of the belt. Measuring 20.5 inches in length and 0.75 inches in width, this belt suits both manual and robotic finishing operations across a range of metalworking applications.

This belt is used in metalworking environments where a controlled, repeatable finish is required prior to plating, buffing, or final polishing. The flexible cloth backing conforms to contoured surfaces, making it suitable for parts with complex geometry. Its three-dimensional abrasive structure delivers consistent results in automated robotic lines as well as manual bench-grinder and belt-finishing setups common in fabrication shops and finishing departments.

Key Features

• Microreplication technology forms aluminum oxide into self-sharpening pyramids that expose fresh mineral as they wear
• Runs cooler than conventional abrasives, reducing heat-related workpiece distortion
• X-weight cloth backing provides flexibility for finishing over contoured surfaces
• Three-dimensional abrasive design maintains consistent finish throughout belt life, ideal for robotic applications
• Produces finer finishes than conventional electrostatically coated abrasive belts
• Suited for intermediate finishing and fine polishing prior to plating or buffing

Compatibility

Designed for use on belt finishing machines and robotic finishing systems that accept a 20.5-inch by 0.75-inch abrasive belt. Verify machine belt-path dimensions and tension settings before installation.

Installation Notes

Abrasive belts of this type are installed by metalworking or finishing technicians on belt grinders, finishing machines, or robotic abrasive systems. Before changing a belt, power down the machine and allow all moving parts to come to a complete stop. Inspect the contact wheel and platen for wear before mounting a new belt, and confirm belt tracking alignment before resuming operation. Follow the equipment manufacturer's guidelines for belt tension to avoid premature failure or uneven wear.

Technical Specifications

• Belt Length: 20.5 inches
• Belt Width: 0.75 inches
• Abrasive Material: Aluminum Oxide
• Backing Material: X-Weight Cloth
• Color: Gray
• Weight: 0.02 pounds
• Unit of Measure: Each
• UPC: 00051115268199

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010360488
