3M 7010349236 Ring Terminal 22-18 Awg Crimp No. 10 Stud 100-pack

Product Description

The 3M 7010349236 is a partially insulated circular ring terminal designed for secure crimp connections on 22 to 18 AWG copper wire. The ring tongue seats on a No. 10 stud, making it a common choice for control panel wiring, low-voltage circuits, and equipment grounding points. The nylon insulation sleeve is red, indicating compatibility with the 22-to-18 AWG wire range per standard color coding. A copper contact ensures reliable conductivity at the termination point. This terminal is sold in a 100-piece package and is installed by electricians, HVAC technicians, and panel wiring professionals working on residential and light commercial systems.

This ring terminal suits a wide range of applications including HVAC control wiring, electrical panel terminations, automotive wiring, and industrial equipment hookups where a No. 10 stud connection point is present. The crimp-style installation is compatible with standard ratcheting crimp tools used for insulated terminals. The partially insulated design allows the ring tongue to seat flush against the stud surface while the nylon sleeve protects the wire barrel from abrasion and incidental contact. It is appropriate for any 22 to 18 AWG conductor that requires a secure, inspectable ring-lug termination.

Key Features

• Partially insulated nylon sleeve in red for quick AWG range identification
• Crimp connection type for fast, tool-secured termination without soldering
• Compatible wire range: 22 to 18 AWG
• No. 10 stud size fits standard screw terminals and grounding points
• Copper contact material for dependable electrical conductivity
• UL Listed and CSA Certified; RoHS 2011 EU Compliant

Compatibility

Designed for use with 22 to 18 AWG conductors terminated on No. 10 studs in residential, commercial, and light industrial electrical and HVAC control wiring applications.

Installation Notes

Installation should be performed by a qualified electrician or HVAC technician in accordance with NEC requirements for the circuit type and environment. De-energize the circuit completely before terminating or disturbing any wiring connections. Use a ratcheting crimp tool rated for insulated terminals to achieve a proper crimp; avoid over-crimping, which can damage the nylon sleeve and reduce pull-out strength. Inspect each terminated lug for a secure barrel crimp and confirm the ring seats flat against the stud before torquing the fastener.
