3M 7010333954 Vhb Acrylic Foam Tape 45 Mil 0.5 in X 36 Yd Gray

Product Description

The 3M 7010333954 is a gray, double-sided, closed-cell acrylic foam tape sold in a 0.5-inch-wide by 36-yard roll at 45 mil thickness. It carries a pressure-sensitive adhesive on both faces and ships with a PE film liner for handling. The closed-cell foam core gives the tape its combination of structural bonding strength, cushioning, vibration damping, and impact resistance. It bonds high surface energy substrates including metals, coated surfaces, and similar materials. Licensed contractors and industrial maintenance technicians reach for this tape when a permanent, load-bearing bond is needed without mechanical fasteners.

This tape is suited for metal-to-metal bonding applications where parts will proceed through paint or coating processing after assembly. Its excellent temperature resistance makes it appropriate for applications with elevated heat exposure during cure cycles or end-use service. It also serves where cushioning and damping are functional requirements alongside adhesion, such as panel mounting, trim attachment, and vibration isolation in industrial or commercial assemblies. Sold by the roll with a minimum order quantity of 4 rolls.

Key Features

• 45 mil total thickness for a conformable, load-bearing bond layer
• Closed-cell acrylic foam core provides cushioning, damping, and impact resistance
• Pressure-sensitive adhesive on both faces bonds high surface energy substrates
• Suitable for metal bonding prior to paint processing
• Excellent temperature resistance for heat-exposed assemblies
• UL listing 746C
• PE film liner for clean handling and precise application

Compatibility

Designed for bonding high surface energy substrates such as metals and coated materials in industrial, commercial, and manufacturing assembly applications where double-sided foam tape is specified.

Installation Notes

Surface preparation is critical before application — clean bonding surfaces thoroughly to remove oils, dust, and contaminants. Apply firm, even pressure across the full tape length to ensure full adhesive contact. Consult the substrate and application temperature ranges before use in high-heat environments. Installation should follow the jobsite or facility safety protocol for adhesive bonding materials.

Technical Specifications

• Thickness: 45 mil
• Width: 0.5 inches
• Length: 36 yards
• Color: Gray
• Construction: Closed-cell acrylic foam, double-sided pressure-sensitive adhesive
• Liner: PE film
• Weight: 0.96 pounds
• Unit of Measure: Roll
• Certification: UL 746C
• UPC: 00021200563119

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010333954
