3M 7010327454 Ceramic Cartridge Roll 80 Grit 0.25x1.5x0.125 in

Product Description

The 3M 7010327454 is a ceramic grain abrasive cartridge roll built for aggressive material removal in tight or contoured areas. Mounted on an X-weight cloth backing, this roll offers the rigidity and durability required for demanding grinding applications. The resin bond construction resists heat buildup during extended use, and an integrated grinding aid promotes cooler grinding to extend abrasive life and protect workpiece surfaces. Rated at 80 grit, it delivers a fast cut suitable for stock removal and surface conditioning on metals and other hard materials. Licensed trades and skilled fabricators rely on this format for precision work in die grinders and rotary tools.

This cartridge roll is suited for use in metal fabrication shops, maintenance and repair operations, and industrial finishing environments. The 0.25-inch mandrel diameter, 1.5-inch length, and 0.125-inch wall thickness make it compatible with standard cartridge roll mandrels used in die grinders and straight-shaft rotary tools. Typical applications include weld blending, deburring, chamfering, and surface prep on ferrous and non-ferrous metals in both shop and field settings.

Key Features

• Ceramic grain abrasive for high cut rate and extended service life
• X-weight cloth backing provides durability and resistance to tearing under load
• Resin bond construction enhances heat resistance during aggressive grinding
• Grinding aid promotes cooler cut, reducing heat damage to workpiece and abrasive
• 80 grit rating suited for stock removal and surface conditioning
• Compact cartridge roll format designed for use in die grinders and rotary tools

Compatibility

Designed for use with standard cartridge roll mandrels accepting a 0.25-inch inside diameter roll in die grinders and straight rotary power tools used in metal fabrication and finishing applications.

Installation Notes

Installation is performed by qualified operators familiar with rotary abrasive tooling. Confirm the mandrel diameter matches the roll inside diameter before mounting, and ensure the mandrel nut is securely tightened before operation. Verify that the tool RPM rating does not exceed the maximum rated speed of the abrasive roll. Always wear appropriate personal protective equipment including eye protection and gloves when operating rotary abrasive tools.

Technical Specifications

• Abrasive Grain: Ceramic
• Grit: 80
• Grade: X-Weight
• Backing Material: Cloth
• Bond Type: Resin
• Inside Diameter: 0.25 inches
• Length: 1.5 inches
• Wall Thickness: 0.125 inches
• Unit of Measure: Roll
• Minimum Order Quantity: 100
• UPC: 00051141203980

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010327454
