3M 7010326163 Ao Cloth Sanding Belt 48x2.5 in P120

Product Description

The 3M 7010326163 is an aluminum oxide cloth abrasive belt designed for metal deburring, general metalworking, and woodworking material removal. Constructed on an X-weight cloth backing, the belt withstands the rigors of heavy sanding and grinding cycles. A resin bond system holds the aluminum oxide mineral under high heat and pressure, maintaining consistent cut rate throughout the belt's service life. At 48 inches long and 2.5 inches wide with a P120 grit rating, this belt is sized for wide belt, edge, and portable belt sanding applications. Licensed trades and production grinding operators are the primary users.

This belt is suited for both metal and wood substrates in residential shop, light industrial, and production metalworking environments. Its tube-shaped band profile allows it to conform to inner and outer contours, making it effective for removing parting lines, surface imperfections, and burrs from machined or cast components. The belt is also compatible with rubber expander wheel attachments, enabling use with a die grinder or rotary drill for portable, detail-oriented deburring work. Wide belt sanders, edge sanders, and portable belt sanders are all supported configurations.

Key Features

• X-weight cloth backing handles heavy sanding and grinding pressure without tearing
• Resin bond resists high heat and pressure for extended service life
• Aluminum oxide mineral delivers fast cut on metal and wood substrates
• Tube-shaped band profile conforms to inner and outer contours for burr and parting-line removal
• Compatible with rubber expander wheel attachments for use with die grinders and rotary drills
• Suitable for wide belt, edge, and portable belt sanding configurations

Compatibility

Designed for use on metal substrates including machined and cast components, as well as wood. Fits wide belt sanders, edge sanders, and portable belt sanders. Accepts rubber expander wheel attachments (sold separately) for use with die grinders or rotary drills.

Installation Notes

Ensure the sanding machine or die grinder is fully powered off and unplugged before mounting or removing the belt. Verify the belt arrow or grain direction marking aligns with the direction of travel on the machine. Inspect the expander wheel or contact drum for wear or damage before seating the belt. Follow machine manufacturer guidelines and applicable shop safety standards when operating abrasive belts at rated speeds.

Technical Specifications

• Abrasive Mineral: Aluminum Oxide
• Backing Material: X-Weight Cloth
• Bond Type: Resin
• Grit: P120
• Belt Length: 48 inches
• Belt Width: 2.5 inches
• Weight: 0.14 pounds
• UOM: Each
• UPC: 00051144265442

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010326163
