3M 7010325828 Abrasive Belt 156x4 Inch P150 Grit Silicon Carbide

Product Description

The 3M 7010325828 is a coated abrasive belt designed for grinding, blending, deburring, and finishing on metal surfaces. Built around sharp silicon carbide mineral, this belt fractures consistently during use to expose fresh cutting edges, maintaining finish quality throughout the belt's service life. The abrasive is bonded to a tough polyester cloth backing using a heat-resistant resin that holds up under pressure, heat, and wet conditions. At P150 grit, it delivers a fine, consistent surface finish suited to finishing and light deburring passes. The belt measures 156 inches in length and 4 inches in width, sized for backstand applications.

This belt is intended for use on metal backstand grinders in fabrication, metalworking, and manufacturing environments. It handles both wet and dry operation, making it adaptable to shops that use coolant or prefer dry grinding. The water-resistant polyester backing resists tearing and nicking under heavy use. Licensed tradespeople, fabricators, and metal finishing technicians working in industrial or commercial settings are the primary users. It is well suited to stainless steel, carbon steel, and nonferrous metals where a controlled, repeatable finish is required.

Key Features

• Silicon carbide mineral fractures consistently, maintaining cut rate and finish quality over belt life
• P150 grit produces a fine surface finish suitable for finishing and light deburring on metal
• Heat-resistant resin bond holds abrasive securely under pressure, heat, and water exposure
• Tough polyester cloth backing supports wet or dry applications without tearing or nicking
• Sized for backstand use at 156 inches long by 4 inches wide
• Black color coding aids grit identification in multi-grit shops

Compatibility

Designed for use on backstand grinders accepting a 4 inch wide by 156 inch abrasive belt for grinding and finishing on all metals.

Installation Notes

Installation should be performed by a qualified operator familiar with abrasive backstand equipment. Power down and lock out the grinder before mounting or removing the belt. Confirm belt tracking and tension before resuming operation, and verify the machine's rated speed does not exceed the belt's maximum operating speed. Eye protection and appropriate PPE are required when operating abrasive equipment.

Technical Specifications

• Belt Length: 156 inches
• Belt Width: 4 inches
• Grit: P150
• Abrasive Mineral: Silicon Carbide
• Backing Material: Polyester Cloth
• Bond Type: Heat-Resistant Resin
• Color: Black
• Application: Grinding, Blending, Deburring, Finishing on Metal
• Operating Conditions: Wet or Dry
• Weight: 0.8 pounds
• UPC: 00051125247740

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010325828
