3M 7010325610 Lapping Film Disc 5 Inch 0.5 Micron

Product Description

The 3M 7010325610 is a 5-inch lapping film disc designed for precision lapping and polishing of a wide range of substrates. It features cerium oxide mineral — noted as 0.5 micron grade in the 562X lapping film series — coated onto a 3-mil polyester film backing. This construction delivers a consistent, controlled cut while producing a fine, repeatable surface finish. The disc is intended for dry, non-slurry processing environments, making it a clean-running option for production and bench polishing operations. Technicians and process engineers working in fiber optic, optical, or precision metalworking applications will find this disc suited to demanding finish requirements.

This lapping film disc is used in precision polishing and lapping applications across industrial and manufacturing settings. Typical applications include end-face polishing of fiber optic connectors, optical lens finishing, and surface preparation of precision components where a controlled, fine surface finish is required. The non-slurry design supports dry processing workflows without the mess and disposal requirements of traditional slurry-based lapping compounds.

Key Features

• 0.5 micron cerium oxide mineral for fine, controlled surface finishing
• 3-mil polyester film backing provides dimensional stability during lapping
• Non-slurry processing keeps the work area clean and simplifies waste handling
• Consistent mineral coating supports repeatable surface finish results
• Designed to reduce overall process cycle time

Compatibility

Designed as an OEM-style replacement lapping disc for use with standard 5-inch lapping and polishing fixtures in precision manufacturing and optical finishing applications.

Installation Notes

This disc is installed and handled by precision manufacturing technicians or fiber optic polishing specialists. Ensure the lapping fixture or polishing puck is clean and free of debris before mounting the disc to prevent contamination of the abrasive surface. Apply uniform pressure during lapping to maintain even wear and consistent finish quality. Dispose of used discs in accordance with facility waste handling procedures for abrasive materials.

Technical Specifications

• Disc Diameter: 5 inches
• Mineral Type: Cerium Oxide
• Mineral Grade: 0.5 micron
• Backing: 3-mil polyester film
• Processing Type: Non-slurry
• Package Weight: 2.28 pounds
• Package Length: 7.71 inches
• Package Width: 6.88 inches
• Package Height: 4.7 inches
• Unit of Measure: Each
• UPC: 051111724656

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010325610
