3M 7010320062 FP-301 Heat Shrink Tubing 1/16 in Blue 1000 Ft

Product Description

The 3M 7010320062 is a thin-wall heat shrink tubing sold on a 1000-foot bulk spool, part of the FP-301 product family. FP-301 tubing is a general-purpose, single-wall polyolefin heat shrink designed to provide insulation, environmental sealing, and strain relief on wire, cable, and electrical connections. It delivers a reliable balance of electrical, physical, and chemical resistance properties suited to demanding industrial and military wiring applications. The 1/16-inch nominal diameter targets small-gauge conductors and fine wire bundles. The blue color allows color-coded identification of circuits or wire groupings in the field.

This tubing is used across a broad range of industrial, military, and commercial electrical applications wherever a compact, thin-wall heat shrink solution is required. Typical scenarios include insulating splices, protecting terminal connections, bundling small-gauge wire assemblies, and providing mechanical protection on exposed conductors. The bulk 1000-foot spool format is suited to production environments, panel shops, and field service operations that consume tubing at volume.

Key Features

• FP-301 single-wall polyolefin construction provides dielectric insulation and chemical resistance
• Thin-wall profile accommodates tight clearances and small-diameter conductors
• 1/16-inch nominal diameter fits small-gauge wire and fine conductor bundles
• Blue color enables color-coded circuit identification
• 1000-foot bulk spool reduces per-foot cost and supports high-volume use
• Rated for industrial and military application environments

Compatibility

Designed as a general-purpose thin-wall heat shrink tubing suitable for small-gauge wire insulation, splice protection, and conductor bundling in industrial and military electrical assemblies.

Installation Notes

Heat shrink tubing of this type is installed by electricians, harness assemblers, and field service technicians using a heat gun or regulated hot-air tool. De-energize all circuits and verify zero voltage before applying tubing to any live conductor. Apply heat evenly along the length of the tubing to achieve uniform shrinkage without scorching the substrate. Follow applicable NEC requirements and any relevant military or industrial wiring standards for the specific installation.

Technical Specifications

• Nominal Diameter: 1/16 inch
• Color: Blue
• Spool Length: 1000 feet
• Wall Type: Thin-wall, single-wall
• Material: Polyolefin
• Unit of Measure: Foot
• Minimum Order Quantity: 3000 feet
• UPC: 00054007087465
• Weight: 0.01 pounds

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010320062
