3M 7010313024 Vinyl Tape 472 Black 20.75in X 36yd 10.4 Mil

Product Description

The 3M 7010313024 is a heavy-duty vinyl tape supplied on a liner, configured at 20.75 inches wide by 36 yards long at a 10.4 mil total thickness. It combines a vinyl backing with a rubber-based adhesive to deliver strong abrasion resistance and reliable adhesion across a range of industrial applications. The tape withstands temperatures up to 225 degrees F and resists most common solvents, making it suitable for demanding environments where standard tapes fail. Licensed trades and industrial technicians specify this tape when durable surface protection or a sealing barrier is required.

This tape is used across heavy-duty protection and abrasion resistance applications, including splicing and patching, outdoor weathering installations, electroplating processes, and dissimilar metal separation. It also performs as a sealing barrier for films and containers and provides corrosion protection for metal surfaces. The untrimmed edge variant is included, which is relevant for precision masking and electroplating operations where edge coverage is critical. Suitable for both shop and field use in industrial, electrical, and HVAC contexts.

Key Features

• 10.4 mil total thickness for heavy-duty abrasion resistance
• Vinyl backing with rubber adhesive for strong, flexible bonding
• Temperature resistance up to 225 degrees F
• Resists most common industrial solvents
• Suitable for outdoor weathering and UV-exposed installations
• Supplied on liner with untrimmed edge included for electroplating and precision masking

Compatibility

Designed as an OEM-style industrial vinyl tape for heavy-duty protection, splicing, electroplating, dissimilar metal separation, and sealing applications across industrial, electrical, and mechanical trade environments.

Installation Notes

Surface preparation is critical before application — clean and dry the substrate to ensure full adhesive contact. When used for electroplating or dissimilar metal separation, ensure complete edge coverage to prevent electrolyte intrusion. Power down or de-energize any electrical components before applying tape in electrical enclosures or panel work. Minimum application temperature and surface compatibility should be verified against the end-use environment prior to installation.

Technical Specifications

• Width: 20.75 inches
• Length: 36 yards
• Thickness: 10.4 mil (0.26 mm)
• Backing Material: Vinyl
• Adhesive Type: Rubber
• Temperature Resistance: Up to 225 degrees F
• Color: Black
• Unit of Measure: Roll
• Minimum Order Quantity: 10
• Weight: 13.2 pounds
• UPC: 00051111929643

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010313024
