3M 7010310508 Ao Flap Wheel 6 Inch 150 Grit

Product Description

The 3M 7010310508 is an aluminum oxide flap wheel designed for stock removal, blending, finishing, and cleaning on both inside and outside diameters of metal workpieces. The coated abrasive flaps conform to contoured and radiused surfaces, producing a consistent straight-line finish. A steel mandrel supports the wheel during operation, reducing chatter and operator fatigue. Aluminum oxide abrasive cuts quickly and performs on ferrous and non-ferrous metals alike. This wheel measures 6 inches in diameter and is rated at 150 grit, making it well suited for controlled material removal and surface conditioning in fabrication and metalworking applications.

This flap wheel is intended for use in metalworking environments where consistent coverage on contoured or irregular workpiece profiles is required. Typical applications include deburring, blending welds, finishing pipe interiors and exteriors, and light surface preparation. The 150-grit rating positions this wheel for finish work and aggressive blending rather than coarse stock removal. It is commonly used by fabricators, pipefitters, and metalworkers operating angle grinders or mandrel-driven tools in both shop and field settings.

Key Features

• Aluminum oxide abrasive cuts quickly on ferrous and non-ferrous metals
• Flaps conform to contoured and radiused surfaces for consistent coverage
• Produces a straight-line finish suitable for blending and finishing passes
• Steel mandrel reduces chatter and operator fatigue during extended use
• 150 grit rating suits finish blending, weld blending, and surface conditioning
• 6-inch diameter provides broad contact area on larger workpiece profiles

Compatibility

Designed as an OEM-style replacement flap wheel for use with mandrel-driven rotary tools and angle grinders accepting 6-inch diameter flap wheel accessories.

Installation Notes

Mounting and operation should be performed by qualified metalworking personnel familiar with abrasive wheel safety. Inspect the wheel for damage before mounting and ensure the tool spindle speed does not exceed the rated RPM of the wheel. Always use appropriate guards and personal protective equipment, including eye and face protection, before operating. Refer to ANSI B7.1 safety standards for abrasive wheel use and handling.

Technical Specifications

• Diameter: 6 inches
• Grit: 150
• Abrasive Material: Aluminum Oxide
• Mandrel Material: Steel
• Package Weight: 4.215 pounds
• Package Length: 6.5 inches
• Package Width: 6.5 inches
• Package Height: 6.75 inches
• Unit of Measure: Each
• Minimum Order Quantity: 5

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010310508
