3M 7010309382 Abrasive Belt 60 Grit 72x6 Inch Ceramic Ao

Product Description

The 3M 7010309382 is a coated abrasive belt designed for high-performance stock removal and metal finishing on production grinding equipment. It combines ceramic abrasive grain with aluminum oxide in a blend that cuts faster and lasts longer than conventional aluminum oxide belts. The heavyweight polyester cloth backing handles high-pressure contact wheel and platen applications without breaking down. A built-in grinding aid reduces heat buildup at the workpiece surface, making this belt well suited for finishing heat-sensitive metals and stainless steel. Licensed metalworkers and grinding machine operators handling structural, sheet, or tube stock are the primary users of this belt.

This belt is used in industrial and fabrication shop environments where high-volume metal grinding and finishing are required. Typical applications include weld blending, deburring, surface conditioning, and coarse finishing on ferrous and non-ferrous metals. The 72-inch length and 6-inch width fit wide-belt and stroke-sander configurations common in metal fabrication. The belt runs effectively both dry and with liquid lubricants or coolants, extending its usable life in wet-process grinding setups.

Key Features

• Ceramic and aluminum oxide grain blend for faster cutting and longer belt life versus standard AO belts
• Heavyweight polyester cloth backing rated for high-pressure contact wheel and platen use
• Grinding aid integrated into bond reduces heat generation on stainless steel and heat-sensitive metals
• Durable resin bond resists heat deterioration, extending service intervals between belt changes
• Runs wet or dry, compatible with water-soluble and oil-based lubricants
• 60 grit designation targets aggressive stock removal and weld blending stages

Compatibility

Designed for use on wide-belt and stroke-sander grinding machines that accept a 72-inch by 6-inch abrasive belt in metal finishing and fabrication applications.

Installation Notes

Belt installation should be performed by qualified machine operators following the grinder manufacturer's belt-tracking and tensioning procedures. Disengage and lock out all power to the machine before changing belts. Inspect the contact wheel, platen, and idler for wear or damage before mounting a new belt. Verify belt arrow direction matches machine rotation before startup to prevent premature joint failure.

Technical Specifications

• Grit: 60
• Abrasive Material: Ceramic Aluminum Oxide Blend
• Belt Length: 72 inches
• Belt Width: 6 inches
• Backing Type: Heavyweight Polyester Cloth
• Bond Type: Resin
• Color: Orange
• Application: Coated, Dry or Wet
• Weight: 0.91 pounds
• UOM: Each

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010309382
