3M 7010307687 Diamond Lapping Film 661X 15.0 Micron Roll

Product Description

The 3M 7010307687 is a diamond lapping film designed for precision surface finishing on extremely hard materials. Precisely graded diamond abrasive particles are coated onto a dimensionally stable polyester film backing, delivering a consistent, repeatable finish pass after pass. This roll measures 1.50 inches wide by 50 feet long and carries a 15.0 micron grade, placing it in the mid-range of the 661X series lineup that spans 0.10 to 30.0 micron. It is used wherever tight surface finish tolerances are required and conventional abrasives fall short.

This lapping film is suited for precision finishing applications across industries that demand controlled material removal and smooth surface profiles. Typical uses include finishing optical fiber connectors, ceramic components, carbide tooling, and other hard substrates. The roll format suits bench lapping fixtures, automated finishing equipment, and custom tooling setups. Machinists, toolmakers, and precision technicians in manufacturing, optical, and specialty trade environments are the primary installers and users of this product.

Key Features

• 15.0 micron diamond abrasive grade for controlled, medium-fine material removal on hard substrates
• Precisely graded diamond particles ensure a consistent, repeatable surface finish
• Polyester film backing provides dimensional stability during use
• 1.50-inch width by 50-foot roll format suits a range of fixtures and automated equipment
• Part of the 661X series, available across grades from 0.10 to 30.0 micron

Compatibility

Designed as an OEM-style lapping film for use with bench lapping fixtures and precision finishing equipment that accept 1.50-inch wide film rolls.

Installation Notes

This product is typically installed and used by machinists, toolmakers, or precision finishing technicians. Ensure the lapping fixture or backing plate is clean and free of debris before loading the film. Secure the roll so the film feeds without slippage or wrinkling during the finishing pass. Follow the equipment manufacturer's guidelines for film tension and feed rate to maintain consistent results.

Technical Specifications

• Grade: 15.0 micron
• Width: 1.50 inches
• Length: 50 feet
• Backing Material: Polyester film
• Abrasive Type: Diamond
• Series: 661X
• Unit of Measure: Roll
• Weight: 1 pound
• UPC: 00051111697887

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010307687
