3M 7010302222 Adhesive Transfer Tape 7 Inch 60 Yd

Product Description

The 3M 7010302222 is a 10 mil transparent adhesive transfer tape built around 3M High Performance Acrylic Adhesive 100MP. It delivers a thin, double-sided bond layer that conforms to flat, curved, and irregular surfaces across a wide range of industrial and commercial applications. The tape ships on a 58 unprinted polycoated kraft paper liner that supports moisture stability and simplifies die cutting. Each roll is 7 inches wide and 60 yards long, providing ample coverage for high-volume bonding operations. This product is handled and installed by assembly technicians, fabricators, and industrial maintenance professionals.

This tape is suited for both indoor and outdoor applications where a strong, low-profile bond is required. The acrylic adhesive performs reliably across a broad operating temperature range, with continuous service up to 300 degrees F and short-term tolerance up to 500 degrees F. It is commonly used in signage, nameplate attachment, gasket bonding, panel assembly, and similar tasks where a visible fastener is not acceptable. The transparent construction keeps the bond line invisible after application.

Key Features

• 10 mil double-sided transfer tape with high-strength acrylic adhesive for a long-lasting, low-profile bond
• Short-term temperature tolerance up to 500 degrees F (260 degrees C)
• Continuous operating temperature tolerance up to 300 degrees F (149 degrees C)
• Chemical, UV, and solvent resistant adhesive for durable indoor and outdoor service
• 58 unprinted polycoated kraft paper liner provides moisture stability and supports clean die cutting
• Transparent construction leaves no visible bond line after application

Compatibility

Designed as a general-purpose adhesive transfer tape suitable for bonding flat, curved, and irregular surfaces in industrial, commercial, and fabrication applications.

Installation Notes

Surface preparation is critical — clean bonding surfaces with an appropriate solvent and allow to dry fully before applying the tape. Apply firm, even pressure across the entire bond area to ensure full adhesive contact. Remove the liner carefully to avoid stretching or contaminating the adhesive layer. For die-cut applications, use sharp tooling to maintain clean edge geometry and consistent bond performance.

Technical Specifications

• Tape Thickness: 10 mil (0.26 mm)
• Width: 7 inches
• Length: 60 yards
• Short-Term Temperature Tolerance: 500 degrees F (260 degrees C)
• Operating Temperature Tolerance: 300 degrees F (149 degrees C)
• Liner: 58 unprinted polycoated kraft paper
• Adhesive Type: High Performance Acrylic 100MP
• Construction: Double-sided transfer tape
• Color: Transparent
• Unit of Measure: Roll
• Package Weight: 20 pounds
• Package Length: 8.3 inches
• Package Width: 8.3 inches
• Package Height: 10.6 inches
• UPC: 00048011580548

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010302222
