3M 7010301201 Unitized Abrasive Wheel 12 Inch 600 Series

Product Description

The 3M 7010301201 is a 12-inch diameter unitized abrasive wheel from the Standard Abrasives Silicon Carbide 600 Series. It features a soft to medium density construction designed for medium-pressure finishing and polishing on both flat and contoured surfaces. The silicon carbide mineral provides consistent cut on a wide range of base materials. At 2 pounds and 3 inches wide, this wheel is suited for stationary and portable grinding equipment used in metalworking, fabrication, and surface conditioning applications. Machinists, fabricators, and surface finishing technicians are the primary installers and operators of this product.

The 600 Series wheel is appropriate for finishing and polishing operations on ferrous metals, non-ferrous metals, exotic alloys, titanium, and composites. It is commonly used in medium-pressure surface conditioning where a step up in edge durability from a 500 Series wheel is needed. The open web structure resists loading, making it effective for applications where consistent surface finish quality over the life of the wheel is a priority. Both flat and contoured workpiece geometries are addressed by this wheel format.

Key Features

• Soft to medium density silicon carbide construction for medium-pressure finishing and polishing
• Compatible with ferrous metals, non-ferrous metals, titanium, exotic alloys, and composites
• Increased edge durability over 500 Series wheels for extended abrasive service life
• Runs clockwise and counterclockwise for greater versatility across tools and machines
• Open web design resists loading and contributes to longer wheel life

Compatibility

Designed as an OEM-style replacement or direct upgrade for 12-inch unitized abrasive wheel applications requiring a soft to medium density 600 Series silicon carbide wheel on standard arbor-mount grinding and finishing equipment.

Installation Notes

This wheel should be mounted and operated by qualified personnel familiar with abrasive wheel safety standards, including ANSI B7.1 guidelines. Verify that the spindle speed of the tool or machine does not exceed the maximum rated RPM marked on the wheel before mounting. Inspect the wheel for damage before each use and never operate a cracked or compromised wheel. Always use appropriate guarding and personal protective equipment during operation.

Technical Specifications

• Diameter: 12 inches
• Width: 3 inches
• Weight: 2 pounds
• Abrasive Material: Silicon Carbide
• Density: Soft to Medium
• Series: 600
• UPC: 051115355141

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010301201
