3M 7010300674 Scotch-brite Unitized Wheel 6 Inch Fine Grit

Product Description

The 3M 7010300674 Scotch-Brite Unitized Wheel is a 6-inch diameter abrasive wheel built for precision deburring and surface finishing on demanding metals. Using silicon carbide abrasive at a fine grit, this wheel cuts cooler than many conventional abrasives, which helps extend wheel life and reduces the risk of heat damage to workpiece surfaces. Its layered unitized construction is softer and more conformable than higher-density convolute wheels, making it well suited for finishing intricate shapes, tight contours, and narrow-width applications. The wheel weighs 0.16 pounds and measures approximately 6.7 inches in length and width with a 3.1-inch height. It runs clockwise or counterclockwise without performance loss.

This wheel is used in metalworking and fabrication environments where controlled, consistent finishing on stainless steel, titanium, and other hard alloys is required. Its smaller diameter and narrow width capability make it a practical choice for portable tools and smaller bench-mounted equipment. Typical applications include weld blending, edge deburring, and pre-inspection surface prep in light manufacturing, maintenance, and fabrication shops. A licensed or trained metalworking technician or fabricator is the expected installer and operator.

Key Features

• Silicon carbide abrasive at fine grit for controlled finishing on stainless steel and titanium
• Layered unitized construction runs clockwise or counterclockwise
• Resists loading and runs cool, extending wheel service life
• Conformable construction handles intricate shapes and contours
• Suitable for very narrow widths and small diameters where convolute wheels cannot be used
• Compatible with smaller and portable equipment

Compatibility

Designed for use on portable and bench-mounted abrasive equipment that accepts 6-inch unitized wheels. Consult tool manufacturer specifications for maximum allowable RPM and arbor size before mounting.

Installation Notes

Mounting and operation should be performed by qualified personnel familiar with abrasive wheel safety. Always power down and de-energize the tool before mounting or changing the wheel. Inspect the wheel for damage before each use and confirm the tool's rated RPM meets or exceeds the wheel's rated speed. Follow ANSI B7.1 safety standards for the use, care, and protection of abrasive wheels.

Technical Specifications

• Abrasive Type: Silicon Carbide
• Grit: Fine
• Wheel Diameter: 6 inches
• Package Length: 6.7 inches
• Package Width: 6.7 inches
• Package Height: 3.1 inches
• Weight: 0.16 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 8

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010300674
