3M 7010297782 Female Wire Disconnect 16-14 Awg 100 Pack

Product Description

The 3M 7010297782 is a fully insulated female wire disconnect connector designed for fast, reliable push-on terminations in low-voltage wiring applications. Built with a blue nylon insulating sleeve, this connector accepts 16 to 14 AWG wire and mates with a 1/4 inch tab. The full insulation jacket protects the connection point from accidental contact and environmental exposure. HVAC technicians, electricians, and control wiring installers use this style of disconnect where serviceable, tool-free terminal connections are required on control boards, relays, thermostats, and similar components. This package includes 100 connectors.

These female disconnect terminals are a standard fit for residential and light commercial wiring tasks. Common applications include HVAC control wiring, appliance harness repair, panel wiring, and general electrical assembly work where 16 to 14 AWG conductors are terminated to 1/4 inch blade-style tabs. The blue color coding indicates compatibility with the 16-14 AWG wire range, making visual identification straightforward during installation or service calls.

Key Features

• Fully insulated nylon sleeve in blue for AWG 16-14 wire range identification
• Accepts 1/4 inch tab width blade terminals
• Female disconnect style for push-on, removable connections
• Nylon insulation resists abrasion and moderate heat in typical control wiring environments
• RoHS 2011/65/EU compliant — meets restriction of hazardous substances requirements
• Package quantity of 100 supports bulk service or installation work

Compatibility

Designed for use with 16 to 14 AWG conductors and 1/4 inch male blade tab terminals common in HVAC control circuits, appliance wiring, and general electrical assemblies.

Installation Notes

Installation is performed by electricians or HVAC technicians following applicable NEC requirements for the circuit being terminated. De-energize the circuit before making or breaking connections. Strip the conductor to the length specified by the connector barrel, insert fully, and crimp with an appropriate ratcheting or plier-style crimp tool rated for insulated disconnects. Inspect the insulation sleeve after crimping to confirm no cracking or splitting at the barrel entry point.
