3M 7010294795 Flap Disc 577F 4 Inch 40 Grit Type 29

Product Description

The 3M 7010294795 is a Type 29 quick-change flap disc designed for high-pressure metalworking. It uses alumina zirconia mineral bonded to heavyweight polyester-backed flaps, delivering faster cutting than standard aluminum oxide abrasives across all metal types. At 4 inches in diameter and 40 grit, it is built for aggressive stock removal while leaving a blended finish in the same pass. Typical applications include weld removal, beveling, and sharp-edge work on ferrous and non-ferrous metals. The quick-change attachment system reduces disc swap time during production grinding work.

This disc is suited for fabrication shops, maintenance facilities, and industrial metalworking environments where both grinding and finishing are required in a single operation. The Type 29 conical flap design increases surface contact on flat and contoured workpieces. It is sold individually and fits grinders with a compatible quick-change arbor system. Minimum order quantity is 10 units.

Key Features

• Alumina zirconia mineral with grinding aid cuts faster than aluminum oxide on all metal types
• Flap design combines grinding and blending into one step, reducing total process time
• Heavyweight polyester-backed flaps extend disc life under high-pressure conditions
• Quick-change mounting system speeds up disc changes and reduces downtime
• Type 29 conical profile improves contact angle on flat and contoured surfaces

Compatibility

Designed for use with quick-change angle grinders accepting 4 inch Type 29 flap discs. Suitable for grinding and blending operations on steel, stainless steel, and other metals.

Installation Notes

Installation should be performed by qualified personnel following the grinder manufacturer's mounting instructions. Always power down and disconnect the grinder before changing discs. Confirm the disc RPM rating meets or exceeds the grinder's no-load RPM before use. Wear appropriate PPE including eye protection and gloves during disc changes and operation.

Technical Specifications

• Disc Diameter: 4 inches
• Grit: 40
• Disc Type: Type 29 (Conical)
• Abrasive Mineral: Alumina Zirconia
• Backing Material: Heavyweight Polyester
• Attachment Style: Quick Change
• Weight: 0.54 pounds
• Package Length: 5.8 inches
• Package Width: 6.4 inches
• Package Height: 6.2 inches
• Sold As: Each
• Minimum Order Quantity: 10
• UPC: 00051141275307

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010294795
