3M 7010045125 High Temp Nylon Film Tape 1in X 72yd 6mil

Product Description

The 3M 7010045125 is a high temperature nylon film tape designed for demanding masking and composite fabrication work. Built on a 6.0 mil nylon film backing, it uses a non-silicone rubber adhesive that maintains bond integrity under elevated process temperatures. The roll measures 1 inch wide by 72 yards long, giving technicians a substantial run length per roll for continuous masking operations. This tape is suited for aerospace, industrial composites, and metal bonding applications where silicone contamination is not acceptable and clean removal is required after cure cycles.

This tape is used in advanced composite and metal bond masking applications. It performs in composite bagging operations and helps facilitate clean flashing removal after composite bonding processes. The non-silicone adhesive system makes it appropriate for environments where silicone transfer would compromise surface finish, coating adhesion, or secondary bonding. Composite fabricators, aerospace technicians, and industrial assembly professionals are the primary installers of this product.

Key Features

• 6.0 mil nylon film backing rated for high temperature process exposure
• Non-silicone rubber adhesive prevents silicone contamination on bonded surfaces
• 1 inch width by 72 yard length per roll for extended masking runs
• Supports composite bagging operations and post-bond flashing removal
• White film allows visual confirmation of tape placement on dark substrates

Compatibility

Designed for use in advanced composite masking, metal bond masking, and composite bagging operations where a non-silicone, high temperature film tape is required.

Installation Notes

Application should be performed by qualified composite fabricators or industrial technicians familiar with surface prep requirements for bonding operations. Ensure the substrate is clean and free of contaminants before applying tape. Follow the composite process specification for cure temperature limits to confirm this tape is appropriate for the thermal cycle. Remove tape carefully after cure to avoid tearing or leaving adhesive residue on finished surfaces.

Technical Specifications

• Backing Material: Nylon film
• Backing Thickness: 6.0 mil (0.15 mm)
• Adhesive Type: Non-silicone rubber
• Width: 1 inch
• Length: 72 yards
• Color: White
• Unit of Measure: Roll
• Weight: 0.37 pounds

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7010045125
