3M 7000148880 Fire Barrier Metal Deck Adaptor

Product Description

The 3M 7000148880 is a metal deck adaptor designed for use with the 6-inch 3M Fire Barrier Cast-In Device. It allows the cast-in device to be mounted on fluted metal deck assemblies, which require a minimum concrete topping of 4.5 inches. The adaptor accommodates both metallic and non-metallic models of the 3M Fire Barrier Cast-In Device, making it a versatile component in fire-rated floor-ceiling assembly work. Licensed fire protection contractors and commercial electricians typically specify this adaptor during new construction on steel-framed structures with composite deck systems.

This adaptor is intended for commercial and industrial construction applications where fire-rated penetration sealing is required through fluted metal deck floors. It is used during the rough-in phase, before concrete is poured, to position the cast-in device correctly within the deck profile. The minimum 4.5-inch concrete topping requirement must be confirmed during the planning stage to ensure compliance with the fire-rated assembly design.

Key Features

• Compatible with 6-inch 3M Fire Barrier Cast-In Device models
• Designed for installation on fluted metal deck assemblies
• Accommodates both metallic and non-metallic cast-in device models
• Requires a minimum 4.5-inch concrete topping over the metal deck
• Sold individually (each)

Compatibility

Designed for use with the 6-inch 3M Fire Barrier Cast-In Device in both metallic and non-metallic configurations. Suitable for fluted metal deck floor assemblies with a minimum 4.5-inch concrete topping.

Installation Notes

Installation is typically performed by licensed fire protection contractors or commercial electricians during the pre-pour phase of construction. Confirm the concrete topping depth meets the 4.5-inch minimum before positioning the adaptor. Follow the applicable fire-rated assembly design documentation and local building code requirements. Do not install in assemblies that do not meet the specified concrete topping thickness, as this will affect the fire rating.

Technical Specifications

• Compatible Device Size: 6 inches
• Minimum Concrete Topping Required: 4.5 inches
• Weight: 0.68 pounds
• Unit of Measure: Each
• Minimum Order Quantity: 12
• UPC: 00051115165474

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000148880
