3M 7000145501 Glass Cloth Tape 0.5in X 66ft White Silicone

Product Description

The 3M 7000145501 is a 7 mil woven glass cloth tape with a silicone pressure-sensitive adhesive, designed for high-temperature electrical insulation applications. Rated to 180 degrees C and UL Recognized, it delivers reliable performance in demanding coil winding, banding, and insulation jobs. The white tape is edge-tear resistant and conformable, making it practical for wrapping irregular geometries without splitting or delaminating. Its silicone adhesive system bonds securely at elevated temperatures where conventional acrylic or rubber-based adhesives fail. Licensed electricians and motor winding technicians are the primary installers of this product.

This tape is suited for residential and commercial electrical motor coil insulation, transformer winding, and cable harnessing work. Typical applications include coil cover wrapping, anchor and banding duties, core insulation, layer insulation, and crossover insulation in high-heat environments. The tape is also printable, allowing field or shop marking directly on the surface. It is recommended for use alongside 3M 77 Electric Arc-Proofing Tape in arc-proofing assemblies. Each roll is wound on a 1 inch core and sold individually, with 10 rolls per carton.

Key Features

• 7 mil woven glass cloth construction provides strength and conformability
• Silicone pressure-sensitive adhesive rated to 180 degrees C for sustained high-temperature service
• UL Recognized at 180 degrees C for electrical insulation applications
• Edge-tear resistant and flame resistant for safer handling in the field
• Printable surface supports field identification and labeling
• Wound on a 1 inch core for compatibility with standard tape dispensing equipment

Compatibility

Recommended for use with 3M 77 Electric Arc-Proofing Tape. Designed as an OEM-style insulation tape for high-temperature coil winding, banding, and electrical insulation assemblies in both residential and commercial motor and transformer applications.

Installation Notes

Installation should be performed by a licensed electrician or qualified motor winding technician. De-energize and lock out all equipment before applying tape to coils, windings, or cable assemblies. Apply with firm, even pressure to ensure full adhesive contact, particularly on curved or irregular surfaces. Follow applicable NEC guidelines and equipment manufacturer procedures for high-temperature insulation systems.

Technical Specifications

• Tape Thickness: 7 mil
• Width: 0.5 inches
• Length: 66 ft
• Color: White
• Adhesive Type: Silicone pressure-sensitive
• Temperature Rating: 180 degrees C
• Core Size: 1 inch
• Weight: 0.17 pounds
• Unit of Measure: Roll
• UPC: 00054007100836

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000145501
