3M 7000133356 Insulated Disconnect Terminal 600 VAC 22 to 18 AWG 1/4 in

Product Description

3M 7000133356 is an insulated standard female disconnect terminal. It supports conductor sizes from twenty-two to eighteen AWG and works with a quarter inch tab. The terminal features a zero point zero eight inches inner diameter butted barrel designed for reliable connections.

• Supports twenty-two to eighteen AWG conductors.
• Voltage rating of six hundred VAC.
• Temperature rating from negative forty to two hundred twenty-one degrees Fahrenheit.

Product Highlights

This terminal provides secure connections for various electrical applications and ensures durability with its ETP copper construction.

Product Information

Standard Information

• Brand: 3M
• MPN: 7000133356

Technical Specifications

• Type: Insulated Standard
• Voltage Rating: 600 VAC
• Conductor Size: 22 to 18 AWG
• Dimensions: 1/4 in W x 0.032 in THK Pad
• Specifications: 0.87 in OAL
• Barrel Type: 0.08 in ID Butted
• Material: ETP Copper
• Color: Red
