3M 7000132375 Heat Shrink Heavy-Wall Cable Sleeve 1kV (12 in Length)

Product Description

The 3M Heat Shrink Heavy-Wall Cable Sleeve, MPN 7000132375, is designed for reliable performance in electrical splices, connections, and terminations. This sleeve measures twelve inches in length and accommodates wire sizes from 250 to 750 kcmil. It features a cross-linked polyolefin material making it resistant to splits and fast-shrinking for quick installation.

• Heavy-duty construction for environmental protection.
• Factory-applied adhesive for secure bonding during installation.
• Rated for voltage applications up to 1 kV, UL Listed 486 D for 600V.

Product Highlights

Ideal for various electrical applications, this heat shrinkable sleeve offers excellent moisture sealing and physical protection against mechanical stress and environmental factors.

Product Information

Standard Information

• Length: 12 inches
• Material: Cross-linked polyolefin

Technical Specifications

• Voltage Rating: 600 VAC
• Shrink Ratio: 3:1
• Operating Temperature: -55 to 100 degrees Celsius
• Inner Diameter Expanded: 2 inches
• Inner Diameter Recovered: 0.65 inches
• Color: Black
