3M 7000132167 Emi Shielding Foil Tape 1in 18yd 600V

Product Description

The 3M 7000132167 is an aluminum foil tape with acrylic adhesive, engineered for EMI shielding, grounding, and static charge draining in electrical and electronic applications. Sold as a 1-inch-wide, 18-yard roll, this tape delivers reliable point-to-point electrical contact across a broad operating temperature range of -40 to 266 degrees F (-40 to 130 degrees C). It is rated for 600-volt dry applications and carries a flame-retardant construction. The tape ships on a removable liner that simplifies die cutting and precise placement on assemblies, enclosures, and cable bundles.

This tape is suited for use in commercial and industrial settings where EMI attenuation, chassis grounding, or static drain paths are required. Electricians, electronics technicians, and panel fabricators commonly use it when terminating shielded cable assemblies, sealing seams in metal enclosures, or bonding foil barriers inside control panels and equipment housings. The 1-inch width accommodates narrow shielding runs and overlap joints without excess material waste.

Key Features

• Acrylic adhesive creates secure, continuous electrical contact with metal surfaces
• Suitable for EMI shielding, equipment grounding, and static charge draining
• Flame-retardant construction for use in code-sensitive electrical environments
• Rated for 600V dry applications
• Operates from -40 to 266 degrees F (-40 to 130 degrees C)
• UL Listed and RoHS 2011/65/EU compliant
• Removable liner supports clean die cutting and precise handling

Compatibility

Designed as an OEM-style shielding and grounding tape for use in electrical enclosures, shielded cable assemblies, and EMI-sensitive electronic equipment installations where a conductive aluminum foil tape with acrylic adhesive is specified.

Installation Notes

Installation is performed by electricians or electronics technicians following applicable NEC guidelines for bonding and grounding. De-energize all equipment before applying tape to live panels or chassis. Clean and degrease the target surface before application to ensure full adhesive contact and consistent electrical continuity. Do not use in wet or high-humidity environments, as this product is rated for dry applications only.

Technical Specifications

• Tape Width: 1 inch
• Tape Length: 18 yards
• Voltage Rating: 600V (dry)
• Operating Temperature Range: -40 to 266 degrees F (-40 to 130 degrees C)
• Backing Material: Aluminum
• Adhesive Type: Acrylic
• Flame Rating: Flame-retardant
• Unit of Measure: Roll
• Weight: 3.567 pounds
• Certifications: UL Listed, RoHS 2011/65/EU Compliant

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000132167
