3M 7000090118 Scotch Rubber Splicing Tape 25 mm x 9.15 m (Case of 32)

Product Description

The 3M 7000090118 Scotch Rubber Splicing Tape is a 30 mil self-fusing ethylene propylene rubber tape (25 mm x 9.15 m) for insulating and protecting wire splices and terminations. It features a rubber-resin adhesive and a special polyester liner that will not stick on unwind. Rated for continuous use to 194°F (90°C), the tape provides moisture, UV and ozone resistance and creates a waterproof seal for cable splices up to 69 kV in indoor and outdoor industrial applications.

• Self-fusing ethylene propylene rubber backing with rubber-resin adhesive; 30 mil thickness
• Special polyester non-stick liner for clean unwind; rated continuous to 194°F (90°C)
• Moisture, UV and ozone resistant; forms a waterproof seal for splicing and terminating cables up to 69 kV

Product Highlights

Self-fusing 30 mil splicing tape, 25 mm x 9.15 m, rated to 90°C for up to 69 kV cable splices

Product Information

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000090118
• Country of Origin: United States

Technical Specifications

• Brand: 3M
• Manufacturer Part Number: 7000090118
• Product Name: Scotch Rubber Splicing Tape
• Width: 25 mm (≈0.984 in)
• Length: 9.15 m (≈360.24 in / 30.02 ft)
• Thickness: 30 mil (0.030 in)
• Material / Backing: Self-fusing ethylene propylene rubber
• Adhesive: Rubber-resin adhesive
• Liner: Special polyester liner (non-stick on unwind)
• Temperature Rating: Continuous to 194°F (90°C)
• Maximum Voltage Rating: Up to 69 kV
• Standards / Compliance: ASTM approved; RoHS 2002/65/EC compliant
• Intended Application: Splicing and terminating cables up to 69 kV; electrical insulation and protection for indoor and outdoor industrial use
• Case Pack: Case of 32
