3M 7000058873 Female Wire Disconnect 18-14 Awg 50 Pack

Product Description

The 3M 7000058873 is a fully insulated female wire disconnect designed for fast, reliable IDC (insulation displacement connection) terminations in electrical wiring applications. The blue nylon insulation sleeve covers the full terminal body, protecting against accidental contact and short circuits. Rated for 18-14 AWG wire, this disconnect accepts a 1/4 inch tab width and is packaged in quantities of 50 per pack. It is a standard item for electricians and HVAC technicians who need quick, secure push-on connections in control circuits, appliance wiring, and equipment harnesses.

This female disconnect is suited for residential and light commercial wiring tasks where fast termination without soldering is required. Common applications include HVAC control wiring, motor leads, appliance assembly, and panel wiring. The IDC design allows the terminal to pierce the wire insulation on contact, eliminating the need for wire stripping in supported tool configurations. The blue color coding helps technicians identify the correct terminal for 18-14 AWG wire gauge ranges during assembly and service.

Key Features

• IDC connection type for fast, tool-assisted termination without wire stripping
• Fully insulated blue nylon sleeve for protection and gauge identification
• Compatible with 18-14 AWG wire sizes
• 1/4 inch tab width for standard push-on receptacle fitment
• CSA Certified and UL Listed (UL File E70512, CSA LR32411)
• Packaged 50 per pack for jobsite and shop use

Compatibility

Designed for use with standard 1/4 inch male tab terminals and blade connectors in 18-14 AWG wiring applications. Suitable for OEM and field-service use wherever fully insulated female disconnects are specified.

Installation Notes

Installation should be performed by a qualified electrician or trade technician in accordance with applicable NEC requirements. De-energize and lock out the circuit before terminating or servicing any connections. Use the correct IDC crimping tool rated for this terminal style to ensure a reliable, gas-tight connection. Inspect the insulation sleeve after crimping to confirm full coverage and no deformation.
