3M 7000057832 Vinyl Electrical Tape Super 88 1in X 36yd

Product Description

The 3M 7000057832 is a premium-grade, 8.5-mil thick vinyl electrical insulating tape designed for professional electrical work. Known as Scotch Super 88, it combines a flexible PVC backing with high-performance electrical insulating properties to deliver primary insulation for splices rated up to 600 volts. The tape provides protective jacketing and delivers rapid insulation build-up due to its above-average thickness. Each roll measures 1 inch wide by 36 yards long. It is engineered to perform across a broad temperature range, from 0 degrees F to 220 degrees F, making it suitable for both cold-climate and high-heat installations.

This tape is used by electricians in residential, commercial, and industrial applications where durable, all-weather insulation is required. It is well suited for wire splicing, harnessing, and protective jacketing on conductors and cables. Its all-weather formulation makes it a reliable choice for outdoor installations and conduit work where exposure to moisture, UV rays, and temperature extremes is expected. UL Listed and CSA Certified, this tape meets the compliance requirements commonly called for in NEC-governed installations.

Key Features

• 8.5-mil thick PVC backing for faster insulation build-up compared to standard-grade tapes
• Primary electrical insulation rated for splices up to 600 volts
• All-weather performance from 0 degrees F to 220 degrees F
• Excellent resistance to UV rays, moisture, abrasion, copper corrosion, alkalies, and acids
• UL Listed and CSA Certified for professional electrical applications
• Flexible PVC backing conforms to irregular surfaces and cable geometries

Compatibility

Designed as a professional-grade vinyl electrical tape for use in standard electrical insulation, splicing, and jacketing applications on conductors and cables rated up to 600 volts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out all circuits before applying tape to any conductor or splice. Apply with consistent tension to ensure full adhesion and overlap without gaps. Avoid stretching the tape beyond its designed elongation, as this can reduce long-term insulating performance.

Technical Specifications

• Thickness: 8.5 mil
• Width: 1 inch
• Length: 36 yards
• Voltage Rating: 600 volts
• Temperature Range: 0 degrees F to 220 degrees F
• Backing Material: PVC vinyl
• Weight: 0.59 pounds
• Unit of Measure: Roll
• Certifications: UL Listed, CSA Certified

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000057832
