3M 7000052204 Dual Lock Fastener SJ4580 Clear 1in X 50yd

Product Description

The 3M 7000052204 is a low-profile dual lock reclosable fastener sold in a 1-inch-wide by 50-yard roll. It consists of a clear polypropylene mushroom-stem fastener strip backed with a clear acrylic pressure-sensitive adhesive. When two mating strips are pressed together, the interlocking stems create a firm mechanical closure that can be opened and re-engaged repeatedly. Rated for 100 closure cycles, this fastener is suited for light-duty attachment, panel mounting, and component access applications in indoor environments. Engaged thickness is 0.12 inches, keeping the profile minimal where clearance is limited.

Designed for indoor use in low to medium temperature environments, this fastener handles temperatures up to 158 degrees F. The acrylic adhesive bonds to a wide range of substrates including aluminum, stainless steel, glass, polypropylene, polyethylene, polycarbonate, and ABS plastics, as well as powder-coated paint surfaces and low to medium surface energy materials. Typical applications include securing access panels, electronic enclosures, display components, and lightweight fixtures where tool-free reclosability is required.

Key Features

• Clear polypropylene stem construction with clear acrylic adhesive backing
• Low-profile design at 0.12 inches engaged thickness
• Rated for 100 open-and-close cycles
• Bonds to metals, glass, many plastics, powder-coated surfaces, and low to medium surface energy materials
• 1-inch width on a continuous 50-yard roll for field cutting to length
• Indoor use rated with temperature resistance up to 158 degrees F

Compatibility

Designed for use with mating 3M Dual Lock reclosable fastener strips of the same SJ4580 series. Adheres to metals (aluminum, stainless steel), glass, polypropylene, polyethylene, polycarbonate, ABS plastics, powder-coated paints, and medium to low surface energy materials.

Installation Notes

Clean and dry all bonding surfaces thoroughly before applying the adhesive-backed strip to remove oils, dust, and contaminants that reduce adhesion. Apply firm pressure along the full length of the strip after placement to ensure full adhesive contact. Allow adequate dwell time before loading the joint. This fastener is intended for indoor applications only; do not expose to outdoor weathering or sustained moisture.

Technical Specifications

• Series: SJ4580
• Color: Clear
Width: 1 inch
• Roll Length: 50 yards
• Engaged Thickness: 0.12 inches
• Closure Life: 100 cycles
• Maximum Temperature: 158 degrees F
• Adhesive Type: Clear acrylic pressure-sensitive
• Fastener Material: Clear polypropylene
• Unit of Measure: Roll
• Minimum Order Quantity: 2
• Weight: 2.57 pounds

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000052204
