3M 7000048730 Double Coated Tape 476XL 1in X 540yd 6mil

Product Description

The 3M 7000048730 is a double coated tape with extended liner, sold under the 476XL product line in a translucent format. It features a synthetic rubber adhesive bonded to a polypropylene carrier and backed by a 60 lb densified kraft paper liner. The tape measures 1 inch wide by 540 yards long with a total thickness of 6.0 mil, including a 3.7 mil liner. This construction delivers medium temperature resistance, medium solvent resistance, and strong adhesion performance on both high surface energy (HSE) and low surface energy (LSE) substrates. Licensed tradespeople and industrial maintenance technicians handle typical installations in manufacturing, packaging, and point-of-purchase display environments.

This tape is suited for heavy duty sealing, mounting of promotional materials, core starting operations, and closure of overnight or express boxes, tubes, and envelopes. It also sees regular use in point-of-purchase display assembly and FDA indirect food contact applications, making it appropriate for both industrial production lines and retail display fabrication. The extended liner design supports precise application in high-speed or manual laminating workflows where controlled release and clean transfer are required.

Key Features

• Synthetic rubber adhesive bonds to both HSE and LSE surfaces
• Polypropylene carrier provides dimensional stability during application
• 60 lb densified kraft paper extended liner for controlled release
• 6.0 mil total tape thickness with 3.7 mil liner for consistent gap filling
• Medium temperature and solvent resistance for industrial environments
• Suitable for FDA indirect food contact applications

Compatibility

Designed as an OEM-style double coated tape for use in packaging, mounting, and display fabrication applications requiring adhesion to both high and low surface energy substrates.

Installation Notes

Surface preparation is critical — clean and dry all substrates before application to ensure full adhesive contact. Power down or de-energize any equipment being labeled or assembled before applying tape in electrostatic-sensitive environments. Use a roller or squeegee to eliminate air pockets and ensure uniform bond across the tape width. Handling and disposal should follow applicable facility safety guidelines for adhesive materials.

Technical Specifications

• Width: 1 inch
• Length: 540 yards
• Total Thickness: 6.0 mil
• Liner Thickness: 3.7 mil
• Adhesive Type: Synthetic rubber
• Carrier Material: Polypropylene
• Liner Material: 60 lb densified kraft paper
• Color: Translucent
• Weight: 6.58 pounds
• Unit of Measure: Roll
• Minimum Order Quantity: 6
• UPC: 00021200305979

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000048730
