3M 7000048620 Double Coated Film Tape 9589 White 1in X 36yd

Product Description

The 3M 7000048620 is a double coated film tape built around a 3 mil white high density polyethylene (HDPE) carrier bonded on both sides with 3M Synthetic Rubber Adhesive 760. Total tape thickness is 12.7 mil, supported by a 3.7 mil white densified kraft paper liner that releases cleanly during application. The adhesive system is formulated for high initial tack and excellent quick stick performance at indoor, room-temperature conditions. Tape components comply with Title 21 of the Code of Federal Regulations (21 CFR) as indirect food additives, making it suitable for use in food-adjacent environments where incidental contact is a consideration.

This tape is designed for bonding, mounting, and laminating applications in indoor, room-temperature environments. The synthetic rubber adhesive delivers reliable adhesion to a range of substrates without requiring heat activation. Each roll measures 1 inch wide by 36 yards long, making it practical for production line use, light fabrication, and assembly work. It is commonly used in manufacturing, packaging, and light industrial settings where a clean, double-sided bond is needed without added bulk from foam carriers.

Key Features

• 12.7 mil total tape thickness with 3 mil white HDPE carrier
• 3M Synthetic Rubber Adhesive 760 for high initial adhesion and quick stick
• Short-term heat resistance up to 200 degrees F
• 3.7 mil white densified kraft paper liner for clean, controlled release
• Compliant with 21 CFR requirements as indirect food additives
• 1 inch width by 36 yard length per roll

Compatibility

Designed as an OEM-style double coated film tape for indoor bonding and laminating applications requiring a synthetic rubber adhesive system on an HDPE carrier.

Installation Notes

Surface preparation is critical for maximum adhesion — clean and dry the substrate before application. Apply firm, even pressure across the full tape width after positioning to fully seat the adhesive. Avoid applying in environments below room temperature, as low temperatures reduce initial tack on synthetic rubber adhesive systems. Remove the liner cleanly and avoid stretching the HDPE carrier during application.

Technical Specifications

• Total Tape Thickness: 12.7 mil
• Carrier: 3 mil White High Density Polyethylene (HDPE)
• Adhesive: 3M Synthetic Rubber Adhesive 760
• Liner: 3.7 mil White Densified Kraft Paper
• Width: 1 inch
• Length: 36 yards per roll
• Short-Term Heat Resistance: 200 degrees F
• Regulatory Compliance: 21 CFR Indirect Food Additives
• Weight: 0.65 pounds
• UPC: 00021200232053

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000048620
