3M 7000048528 Repositionable Double Coated Tape 9425 Clear

Product Description

The 3M 7000048528 is a clear, double coated repositionable tape built on a UPVC carrier with a 58 lb. polycoated kraft paper liner. One side carries 3M Acrylic Adhesive 420, a high tack acrylic formulated for strong bonds to plastics and a wide range of substrates. The opposite side uses 3M Repositionable Acrylic Adhesive 1050, a medium tack acrylic that holds reliably and releases cleanly without leaving residue. The tape measures 0.75 inches wide by 72 yards long with a 5.8 mil total thickness. These differential adhesive characteristics make it well suited for temporary mounting, repositionable signage, and clean-removal assembly applications.

This tape is used in light industrial, commercial print, and facilities maintenance environments where a temporary or repositionable bond is required. Adhesive 420 performs across a wide bonding temperature range, with the ability to form bonds at temperatures as low as 32 degrees F and withstand short-term heat exposure up to 300 degrees F. Adhesive 1050 releases cleanly from most surfaces, making this product practical for display graphics, temporary labels, and component positioning tasks where residue-free removal is critical.

Key Features

• Differential double coated construction: high tack Adhesive 420 on one side, medium tack repositionable Adhesive 1050 on the other
• UPVC carrier with 58 lb. polycoated kraft paper liner
• Bonds at temperatures as low as 32 degrees F; short-term heat resistance up to 300 degrees F
• Good chemical resistance and shock resistance on the Adhesive 420 side
• Adhesive 1050 provides clean, residue-free removal from most surfaces
• Clear appearance suitable for visible or light-diffusion applications

Compatibility

Designed as a repositionable double coated tape for general-purpose temporary bonding and mounting applications across a wide range of substrates including plastics, paper, and common commercial surfaces.

Installation Notes

Surface preparation is critical for consistent adhesion — clean surfaces of dust, oil, and moisture before application. Apply firm, even pressure across the tape length to ensure full contact with both substrates. When removing the liner, peel at a low angle to avoid stretching the carrier. Power down or de-energize any equipment before applying tape in electrical or control panel environments.

Technical Specifications

• Width: 0.75 inches
• Length: 72 yards
• Thickness: 5.8 mil
• Color: Clear
• Carrier: UPVC
• Liner: 58 lb. polycoated kraft paper
• Adhesive Side 1: 3M Acrylic Adhesive 420 (high tack)
• Adhesive Side 2: 3M Repositionable Acrylic Adhesive 1050 (medium tack)
• Minimum Bond Temperature: 32 degrees F
• Short-Term Heat Resistance: 300 degrees F
• Weight: 0.87 pounds
• Unit of Measure: Roll

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000048528
