3M 7000044825 Diamond Lapping Film 0.50 Micron Sheet

Product Description

The 3M 7000044825 is a precision diamond lapping film sheet designed for ultra-fine surface finishing of extremely hard materials. Precisely graded diamond abrasive particles are coated onto a dimensionally stable polyester film substrate, producing a consistent, repeatable finish across each pass. The sheet measures 9 inches x 11 inches and carries a 0.50 micron abrasive grade, placing it in the ultra-fine range suited for final-stage lapping and polishing operations. This product is used by trade professionals requiring tight surface finish tolerances on hard substrates including ceramics, carbide, optical components, and fiber optic end faces.

This lapping film is applied in precision finishing operations where surface finish consistency is critical. Typical applications include lapping flat surfaces on valve seats, ceramic components, optical fiber connectors, and hard metal tool faces. The 9 inches x 11 inches sheet format is compatible with hand lapping on flat plates as well as fixture-guided lapping setups. It is sold in individual sheet units with a minimum order quantity of 10 sheets, making it appropriate for shop stock or service kit replenishment.

Key Features

• 0.50 micron abrasive grade for ultra-fine final-stage lapping and polishing
• Precisely graded diamond particles deliver consistent, repeatable surface finishes
• Polyester film backing provides dimensional stability during use
• 9 inches x 11 inches sheet size suits both hand lapping and fixture-guided applications
• Effective on extremely hard materials including carbide, ceramics, and optical components

Compatibility

Designed as an abrasive lapping sheet for use on extremely hard substrate materials requiring ultra-fine surface finish work; no specific equipment or system compatibility is stated by the manufacturer for this SKU.

Installation Notes

This product is used by machinists, tool and die technicians, and precision finishing professionals. Before beginning any lapping operation, ensure the workpiece and lapping surface are clean and free of coarser abrasive contamination that could cause unintended scratching at this fine grade. Use appropriate personal protective equipment including eye protection when working with abrasive films. Follow facility safety procedures for handling and disposing of abrasive materials containing diamond particles.

Technical Specifications

• Abrasive Grade: 0.50 micron
• Sheet Size: 9 inches x 11 inches
• Backing Material: Polyester film
• Abrasive Type: Diamond
• Unit of Measure: Each
• Minimum Order Quantity: 10
• UPC: 00051111497951

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000044825
