3M 7000042539 Vinyl Electrical Tape 1in X 36yd 600V

Product Description

The 3M 7000042539 is a heavy duty vinyl electrical insulation tape rated for use up to 600 volts and 176 degrees F. At 10 mils thick, it is among the thickest vinyl electrical tapes in the Scotch 22 line, built for applications that demand greater mechanical strength and abrasion resistance than standard electrical tape provides. The tape ships in a 1 inch by 36 yard roll format and carries a UL 510 flame-retardant rating. Electricians and maintenance technicians use it where a durable, conformable insulating wrap is required in demanding environments.

This tape is suited for heavy duty insulation applications in both commercial and industrial settings. Typical uses include wire splicing, harnessing, and insulating terminations where mechanical abuse or elevated temperatures are concerns. The 10-mil vinyl construction provides reliable dielectric protection in environments where thinner tapes would be prone to puncture, abrasion, or heat degradation. It is sold by the roll with a minimum order quantity of 12 rolls.

Key Features

• 10-mil vinyl construction for superior mechanical strength and abrasion resistance
• Rated up to 600 volts for electrical insulation applications
• Rated up to 176 degrees F for elevated-temperature environments
• UL Listed per UL 510 with flame-retardant properties
• 1 inch wide by 36 yard roll — standard format for most electrical work

Compatibility

Designed as a heavy duty insulating tape for general electrical insulation tasks up to 600 volts, suitable for wire splicing, harnessing, and termination wrap in commercial and industrial electrical applications.

Installation Notes

Installation is performed by licensed electricians or qualified maintenance personnel. De-energize all circuits before applying insulating tape to any conductor or termination. Ensure the surface is clean and dry for proper adhesion. Follow applicable NEC requirements for the number of tape layers required to achieve rated insulation for the conductor size and voltage class.

Technical Specifications

• Thickness: 10 mil
• Width: 1 inch
• Length: 36 yards
• Voltage Rating: 600 volts
• Temperature Rating: 176 degrees F
• Flame Rating: UL 510 flame-retardant
• Listing: UL Listed
• Weight: 0.71 pounds
• Unit of Measure: Roll
• UPC: 00054007100423

Standard Information

• Brand: 3M
• Manufacturer Part Number: 7000042539
